# Data API builder for Azure Databases



[![NuGet Package](https://img.shields.io/nuget/v/microsoft.dataapibuilder.svg?color=success)](https://www.nuget.org/packages/Microsoft.DataApiBuilder)

[![Nuget Downloads](https://img.shields.io/nuget/dt/Microsoft.DataApiBuilder)](https://www.nuget.org/packages/Microsoft.DataApiBuilder)

[![Documentation](https://img.shields.io/badge/docs-website-%23fc0)](https://learn.microsoft.com/azure/data-api-builder/)

[![License: MIT](https://img.shields.io/badge/license-MIT-blue.svg)](https://opensource.org/licenses/MIT)



[What's new?](https://learn.microsoft.com/azure/data-api-builder/whats-new)



## Community



Join the Data API builder community! This sign up will help us maintain a list of interested developers to be part of our roadmap and to help us better understand the different ways DAB is being used. Sign up [here](https://forms.office.com/pages/responsepage.aspx?id=v4j5cvGGr0GRqy180BHbR1S1JdzGAxhDrefV-tBYtwZUNE1RWVo0SUVMTkRESUZLMVVOS0wwUFNVRy4u).



![](docs/media/dab-logo.png)



## About Data API builder



Data API builder (DAB) is an open-source, no-code tool that creates secure, full-featured REST and GraphQL endpoints for your database. It’s a CRUD data API engine that runs in a container—on Azure, any other cloud, or on-premises. DAB is built for developers with integrated tooling, telemetry, and other productivity features.



```mermaid

erDiagram

    DATA_API_BUILDER ||--|{ DATA_API : "Provides"

    DATA_API_BUILDER {

        container true "Microsoft Container Repository"

        open-source true "MIT license / any cloud or on-prem."

        objects true "Supports: Table / View / Stored Procedure"

        developer true "Swagger / Nitro (fka Banana Cake Pop)"

        otel true "Open Telemetry / Structured Logs / Health Endpoints"

        security true "EntraId / EasyAuth / OAuth / JWT / Anonymous"

        cache true "Level1 (in-memory) / Level2 (redis)"

        policy true "Item policy / Database policy / Claims policy"

        hot_reload true "Dynamically controllable log levels"

    }

    DATA_API ||--o{ DATASOURCE : "Queries"

    DATA_API {

        REST true "$select / $filter / $orderby"

        GraphQL true "relationships / multiple mutations"

    }

    DATASOURCE {

        MS_SQL Supported

        PostgreSQL Supported

        Cosmos_DB Supported

        MySQL Supported

        SQL_DW Supported

    }

    CLIENT ||--o{ DATA_API : "Consumes"

    CLIENT {

        Transport HTTP "HTTP / HTTPS"

        Syntax JSON "Standard payloads"

        Mobile Supported "No requirement"

        Web Supported "No requirement"

        Desktop Supported "No requirement"

        Language Any "No requirement"

        Framework None "Not required"

        Library None "Not required"

        ORM None "Not required"

        Driver None "Not required"

    }

```



## Getting Started



Use the [Getting Started](https://learn.microsoft.com/azure/data-api-builder/get-started/get-started-with-data-api-builder) tutorial to quickly explore the core tools and concepts. It gives you hands-on experience with how DAB makes you more efficient by removing boilerplate code.



**1. Install the DAB CLI**



The [DAB CLI](https://aka.ms/dab/docs) is a cross-platform .NET tool. Install the [.NET SDK](https://get.dot.net) before running:



```

dotnet tool install microsoft.dataapibuilder -g

```



**2. Create your initial configuration file**



DAB requires a JSON configuration file. Edit manually or with the CLI. Use `dab --help` for syntax options.



```

dab init

  --database-type mssql

  --connection-string "@env('my-connection-string')"

  --host-mode development

```



**3. Add your first table**



DAB supports tables, views, and stored procedures. It works with SQL Server, Azure Cosmos DB, PostgreSQL, MySQL, and SQL Data Warehouse. Security is engine-level, but permissions are per entity.



```

dab add Actor

  --source "dbo.Actor"

  --permissions "anonymous:*"

```



**4. Run Data API builder**



In `production`, DAB runs in a container. In `development`, it’s self-hosted locally with hot reload, Swagger, and Nitro (fka Banana Cake Pop) support.



```

dab start

```



> **Note**: Before you run `dab start`, make sure your connection string is stored in an environment variable called `my-connection-string`. This is required for `@env('my-connection-string')` in your config file to work. The easiest way is to create a `.env` file with `name=value` pairs—DAB will load these automatically at runtime.



**5. Access your data source**



By default, DAB enables both REST and GraphQL. REST supports `$select`, `$filter`, and `$orderBy`. GraphQL uses config-defined relationships.



```

GET http://localhost:5000/api/Actor

```



### Walk-through video





  Play Video




Demo source code: [startrek](https://aka.ms/dab/startrek)



## Overview



| Category       | Features |

|----------------|----------|

| **Database Objects** | • NoSQL collections
• RDBMS tables, views, stored procedures |

| **Data Sources** | • SQL Server & Azure SQL
• Azure Cosmos DB
• PostgreSQL
• MySQL |

| **REST** | • `$select` for projection
• `$filter` for filtering
• `$orderBy` for sorting |

| **GraphQL** | • Relationship navigation
• Data aggregation
• Multiple mutations |

| **Telemetry** | • Structured logs
• OpenTelemetry
• Application Insights
• Health endpoints |

| **Advanced** | • Pagination
• Level 1 (in-memory) cache
• Level 2 (Redis) cache |

| **Authentication** | • OAuth2/JWT
• EasyAuth
• Entra ID |

| **Authorization** | • Role-based support
• Entity permissions
• Database policies |

| **Developer** | • Cross-platform CLI
• Swagger (REST)
• Banana Cake Pop (GraphQL)
• Open Source
• Hot Reload |



## How does it work?



This diagram shows how DAB works. DAB dynamically creates endpoints from your config file. It translates HTTP requests to SQL, returns JSON, and auto-pages results.



```mermaid

sequenceDiagram

    actor Client



    box Data API builder (DAB)

        participant Endpoint

        participant QueryBuilder

    end



    participant Configuration as Configuration File



    box Data Source

        participant DB

    end



    Endpoint->>Endpoint: Start

    activate Endpoint

        Endpoint->>Configuration: Request

        Configuration-->>Endpoint: Configuration

        Endpoint->>DB: Request

        DB-->>Endpoint: Metadata

            Note over Endpoint, DB: Some configuration is validated against the metadata

        Endpoint-->>Endpoint: Configure

    deactivate Endpoint

    Client-->>Endpoint: HTTP Request

    activate Endpoint

        critical

        Endpoint-->>Endpoint: Authenticate

        Endpoint-->>Endpoint: Authorize

        end

        Endpoint->>QueryBuilder: Request

        QueryBuilder-->>Endpoint: SQL

        alt Cache

            Endpoint-->>Endpoint: Use Cache

        else Query

            Endpoint-->>DB: Request

            Note over Endpoint, DB: Query is automatically throttled and results paginated

            DB->>Endpoint: Results

            Note over Endpoint, DB: Results are automatically cached for use in next request

        end

        Endpoint->>Client: HTTP 200

    deactivate Endpoint

```



Because DAB is stateless, it can scale up or out using any container size. It builds a feature-rich API like you would from scratch—but now you don’t have to.
