README


# The Dactyl Keyboard

The Dactyl is a parameterized, split-hand, concave, columnar, ergonomic keyboard.



There's a talk about the motivation and design of the Dactyl that helps provide context for this repo:

[![IMAGE ALT TEXT HERE](https://img.youtube.com/vi/uk3A41U0iO4/0.jpg)](https://www.youtube.com/watch?v=uk3A41U0iO4)

## Assembly

### Generating a Design

**Setting up the Clojure environment**

* [Install the Clojure runtime](https://clojure.org)

* [Install the Leiningen project manager](http://leiningen.org/)

* [Install OpenSCAD](http://www.openscad.org/)

**Generating the design**

* Run `lein repl`

* Load the file `(load-file "src/dactyl_keyboard/dactyl.clj")`

* This will regenerate the `things/*.scad` files

* Use OpenSCAD to open a `.scad` file.

* Make changes to design, repeat `load-file`, OpenSCAD will watch for changes and rerender.

* When done, use OpenSCAD to export STL files

**Tips**

* [Some other ways to evaluate the clojure design file](http://stackoverflow.com/a/28213489)

* [Example designing with clojure](http://adereth.github.io/blog/2014/04/09/3d-printing-with-clojure/)

### Printing

Pregenerated STL files are available in the [things/](things/) directory.

### Wiring

Masks for the flexible PCBs I used are available for the [left](resources/pcb-left.svg) and [right](resources/pcb-right.svg) side.

A [very rough guide for the brave is here](guide/README.org#wiring) - It will be improved over time (**TODO**)!

## License

Copyright © 2015 Matthew Adereth

The source code for generating the models (everything excluding the [things/](things/) and [resources/](resources/) directories is distributed under the [GNU AFFERO GENERAL PUBLIC LICENSE Version 3](LICENSE).  The generated models and PCB designs are distributed under the [Creative Commons Attribution-ShareAlike License Version 4.0](LICENSE-models).
