# Automated Sign Language Tutor Project
This is the official repository for the paper _"Automated Sign Language Tutor: A Dual-Language Real-Time Approach
for RSL and ASL"_.
Appearance and video of the stand operation:
Important Note: This repository contains a backend system for sign language recognition (Streaming Sign Recognition Engine and Controller Process components). The provided frontend (ws.html, ws.css, ws.js) serves as a basic example implementation to demonstrate backend functionality and is not a production-ready application. Developers should create their own frontend implementations tailored to specific use cases while using this backend as a recognition service.
It is also possible to use the backend with custom models.
## Key Features
1. **Two operating modes**:
- **LIVE**: Real-time gesture recognition
- **Training**: Mode for teaching the model new gestures
2. **Dual language support**: Russian and English interface and recognition models
3. **WebSocket interaction**: Client sends video stream, server returns recognized gestures
4. **Visual feedback**: Notification system for users
5. **Responsive interface**: Modern design, user-friendly
## Setup and Installation
### Prerequisites
- Python 3.7+
- Node.js (optional for frontend)
- Web camera
### Installing Dependencies
```bash
pip install -r requirements.txt
```
### Models Downloading
Download the models
- https://rndml-team-cv.obs.ru-moscow-1.hc.sbercloud.ru/rsl/demostand_models/tsm/ru/mobilenet_demostand_ru.onnx
- https://rndml-team-cv.obs.ru-moscow-1.hc.sbercloud.ru/rsl/demostand_models/tsm/en/mobilenet_demostand_en.onnx
and place them in the folder `models/checkpoints/`.
### Running the Server
```bash
python server_fapi.py
```
The server will run at `localhost:3003`.
### Docker Deployment
```bash
docker build -t sign-tutor .
docker run -it -d -v $PWD:/app -p 3003:3003 sign-tutor
```
## Using the Web Interface
1. Open `ws.html` in your browser
2. Click "Enable Camera" to access your webcam
3. After enabling the camera, the "Start Stream" button will become available
4. Select operating mode:
- **LIVE**: Real-time gesture recognition
- **Training**:
- Enter gesture name in the text field
- Click "Select Gesture"
- Perform the gesture in front of the camera
- The system will notify you when the gesture is recognized correctly
5. Switching interface and model language: Use the RU/EN buttons in the top right corner
6. The recognition result is displayed in the server console.
## Working with custom models
1. Place ONNX models for Russian and English in the `models/checkpoints/` folder
2. Update the configuration files:
- `models/config_ru.yaml` for the Russian model,
- `models/config_en.yaml` for the English model.
Use the available files as examples.
3. Update the sign class files:
- `models/constants_ru.py ` with the `classes' variable for Russian,
- `models/constants_en.py ` with the `classes' variable for English.
Use the available files as examples.
## System Architecture
### Client-Server Interaction
1. **Establishing connection**:
- Client opens WebSocket connection to `ws://localhost:3003/`
- Server initializes the default language model (Russian)
2. **Main workflow**:
```mermaid
sequenceDiagram
participant Client
participant Server
participant Model
Client->>Server: {"type": "LANGUAGE", "lang": "ru"}
Server->>Model: Initialize Russian model
Model-->>Server: Model ready
Server-->>Client: {"status": 200, "message": "Language changed to ru"}
Client->>Server: {"type": "MODE", "mode": "TRAINING"}
Server-->>Client: {"status": 200, "message": "New MODE TRAINING set correctly"}
Client->>Server: {"type": "GLOSS", "gloss": "привет"}
Server-->>Client: {"status": 200, "message": "New GLOSS привет set correctly"}
loop Each frame (30 FPS)
Server->>Model: Process frame
Model-->>Server: Recognition result
alt Gesture recognized
Server-->>Client: {"text": "привет", "type": "WORD"}
end
end
```
### Key Components
**Client (Frontend)**:
- `view/ws.html`: Main HTML interface file
- `view/ws.css`: Interface styles
- `view/ws.js`: Camera and WebSocket logic
**Server (Backend)**:
- `server_fapi.py`: Main server code (FastAPI)
- `models/model.py`: Recognition model logic
- `Runner`: Class for managing video processing flow
- `RecognitionMP`: Process for gesture recognition in a separate thread
**Model**:
- ONNX models for gesture recognition
- Configuration files for Russian and English versions
- Gesture class files for each language
## Implementation Details
### Client-Side
1. **Camera management**:
- Webcam access via WebRTC
- Frame capture and base64 encoding
- Frame sending at specified frequency (30 FPS)
2. **Mode management**:
- Smooth switching between LIVE and Training modes
- Dynamic UI element display based on current mode
3. **Localization**:
- Full support for Russian and English
- Language preference persistence between sessions
4. **Feedback**:
- Animated notification system
- Visual confirmation of user actions
- Error handling and display
### Server-Side
1. **Video processing**:
- Base64 decoding to OpenCV image
- Frame preprocessing for neural network
- Frame buffering for sequence analysis
2. **Model management**:
- Dynamic model loading for different languages
- Multithreaded processing to minimize latency
- Proper resource cleanup when switching languages
3. **Gesture recognition**:
- Sequence analysis for gesture recognition
- Threshold filtering to reduce false positives
## Configuration and Customization
### Changing Parameters
1. **Frame rate**: Change the `FPS` value in `ws.js`
2. **Video resolution**: Change `width` and `height` attributes of the `` element in `ws.html`
3. **Recognition threshold**: Change the `threshold` value in model configuration files
### Adding New Languages
1. Create a new configuration file `models/config_.yaml`
2. Add a gesture class file `models/constants_.py`
3. Update translation dictionaries in `ws.js`:
```javascript
const translations = {
// ...
: {
title: "...",
startWebcam: "...",
// ... other texts
}
}
```
## Troubleshooting
### Common Issues
1. **Camera not working**:
- Check browser permissions
- Ensure no other applications are using the camera
- Try reloading the page
2. **No connection to server**:
- Ensure the server is running (`python server_fapi.py`)
- Check WebSocket address in `ws.js`
- Ensure no firewall blocking
3. **Model not loading**:
- Check model paths in configuration files
- Ensure model files exist
- Verify content of gesture class files
### Logging
1. **Client**: Open browser developer console (F12)
2. **Server**: Logs are printed in the server console
## Authors
— [Petr Surovtsev]()
— [Alexander Nagaev](https://github.com/nagadit)
— [Alexander Kapitanov](https://github.com/hukenovs/)
— [Ilya Ovodov](https://github.com/IlyaOvodov)
## License
This project is licensed under the APACHE License. See the LICENSE file for details.
For questions and suggestions, please use the project's Issues section.
