# Apache Airflow on Steroids with Java, Scala and Python Spark Jobs
This project orchestrates Spark jobs written in different programming languages using Apache Airflow, all within a Dockerized environment. The DAG `sparking_flow` is designed to submit Spark jobs written in Python, Scala, and Java, ensuring that data processing is handled efficiently and reliably on a daily schedule.
## Project Structure
The DAG `sparking_flow` includes the following tasks:
- `start`: A PythonOperator that prints "Jobs started".
- `python_job`: A SparkSubmitOperator that submits a Python Spark job.
- `scala_job`: A SparkSubmitOperator that submits a Scala Spark job.
- `java_job`: A SparkSubmitOperator that submits a Java Spark job.
- `end`: A PythonOperator that prints "Jobs completed successfully".
These tasks are executed in a sequence where the `start` task triggers the Spark jobs in parallel, and upon their completion, the `end` task is executed.
## Prerequisites
Before setting up the project, ensure you have the following:
- Docker and Docker Compose installed on your system.
- Apache Airflow Docker image or a custom image with Airflow installed.
- Apache Spark Docker image or a custom image with Spark installed and configured to work with Airflow.
- Docker volumes for Airflow DAGs, logs, and Spark jobs are properly set up.
## Docker Setup
To run this project using Docker, follow these steps:
1. Clone this repository to your local machine.
2. Navigate to the directory containing the `docker-compose.yml` file.
3. Build and run the containers using Docker Compose:
```bash
docker-compose up -d --build
```
This command will start the necessary services defined in your docker-compose.yml, such as Airflow webserver, scheduler, Spark master, and worker containers.
## Directory Structure for Jobs
Ensure your Spark job files are placed in the following directories and are accessible to the Airflow container:
* Python job: jobs/python/wordcountjob.py
* Scala job: jobs/scala/target/scala-2.12/word-count_2.12-0.1.jar
* Java job: jobs/java/spark-job/target/spark-job-1.0-SNAPSHOT.jar
These paths should be relative to the mounted Docker volume for Airflow DAGs.
## Usage
After the Docker environment is set up, the `sparking_flow` DAG will be available in the Airflow web UI [localhost:8080](localhost:8080), where it can be triggered manually or run on its daily schedule.
### The DAG will execute the following steps:
* Print "Jobs started" in the Airflow logs.
* Submit the Python Spark job to the Spark cluster.
* Submit the Scala Spark job to the Spark cluster.
* Submit the Java Spark job to the Spark cluster.
* Print "Jobs completed successfully" in the Airflow logs after all jobs have finished.
### Note:
You must add the spark cluster url to the spark connection in the configuration on Airflow UI
### Full Course
[](https://www.youtube.com/watch?v=o_pne3aLW2w)
