## firecracker-init-lab
Build a microVM from a container image
> Many of the examples you'll find are broken due to changes in Firecracker 1.0 - the official quickstart guide doesn't cover the most interesting thing - working Internet access - or extracting a filesystem from a container. This lab extends [the official quickstart](https://github.com/firecracker-microvm/firecracker/blob/main/docs/getting-started.md) so that you can explore what an init process does, and add networking.
## Pre-reqs
* A bare-metal Linux host - [where can you get bare metal?](https://github.com/alexellis/awesome-baremetal#bare-metal-cloud)
* Or a VM that supports nested virtualisation such as on [DigitalOcean](https://m.do.co/c/8d4e75e9886f) or GCP.
* Docker installed
Browse:
* [Go init process](/init/main.go)
* [Makefile](/Makefile)
* [boot.sh](/boot.sh) - commands to start MicroVM
* [setup-networking.sh](./setup-networking.sh) - configure a tap adapter, IP forwarding and IP masquerading
* [Dockerfile](/Dockerfile) - for building the root filesystem
## Usage
Download and install [Firecracker](https://github.com/firecracker-microvm/firecracker/releases) to `/usr/local/bin/`
Or, alternatively, [Arkade](https://arkade.dev) can do this for you with:
```
curl -SLs https://get.arkade.dev | sudo sh
sudo arkade system install firecracker
```
Edit the `IFNAME` in `setup-networking.sh` to match your host's network interface.
Then run the script to create the ftap0 device, and to setup IP masquerading with iptables:
```bash
./setup-networking.sh
```
Download the quickstart Kernel:
```
make kernel
```
Check the Kernel is the correct architecture:
```bash
file ./vmlinux
```
If you don't have the `file` utility, you can add it with `sudo apt install -qy file`
Make the init process binary, and package it into a container, extract the container into a rootfs image:
```bash
make all
```
In one terminal, start firecracker:
```bash
make start
```
In another, instruct it to boot the rootsfs and Kernel:
```bash
make boot
```
Play around in the first terminal and explore the system:
```bash
free -m
cat /proc/cpuinfo
ip addr
ip route
ping -c1 1.1.1.1
echo "nameserver 1.1.1.1" > /etc/resolv.conf
ping -c 4 google.com
apk add --no-cache curl
curl -i https://inlets.dev
```
## Expose a TCP or HTTP service to the Internet
Once you've got something interesting running like a HTTP server, or an SSHD daemon, you can then get ingress from the public Internet using an [inlets tunnel](https://inlets.dev). Inlets is a static binary, and there are a couple of simple tutorials you can follow depending on what you want to expose.
* [HTTPS tunnel with Let's Encrypt](https://docs.inlets.dev/tutorial/automated-http-server/)
* [TCP tunnel for SSH, reverse proxy etc](https://docs.inlets.dev/tutorial/ssh-tcp-tunnel/)
## Running on a Raspberry Pi
Edit Makefile, and change `arch` to `aarch64`
```Makefile
export arch="x86_64"
```
## Snapshot and restore
There is experimental support for snapshot and restore in Firecracker. You will not be able to snapshot on an Intel host and restore on an AMD one, and different generations of CPUs may also be incompatible for snapshot and restore.
You can read more about the current status of snapshot and restore in the [Firecracker docs](https://github.com/firecracker-microvm/firecracker/blob/main/docs/snapshotting/snapshot-support.md)
Run the lab and boot the VM as per the instructions above.
Now, verify the network is up with `ping -c 1 172.16.0.2`
```bash
make pause
make snapshot
```
Kill the Firecracker process, and then restore the snapshot:
```bash
make start
```
In another terminal, restore the snapshot:
```bash
make restore
make resume
```
Run `./setup-networking.sh` again and verify the network is up with `ping -c 1 172.16.0.2`.
