# Partial differential equations (PDE) solvers library
[](https://github.com/andrei-punko/pde-solvers/actions/workflows/gradle.yml)
[](https://github.com/andrei-punko/pde-solvers/actions/workflows/gradle.yml)
[](https://andrei-punko.github.io/pde-solvers/)
[](https://mvnrepository.com/artifact/io.github.andrei-punko/pde-solvers)
[](LICENSE)
A library for numerical solution of partial differential equations (PDE) using finite difference method and Thomas
algorithm
## Features
### Solution of parabolic equations of the form:
```
L(x,t,U)*∂U/∂t = ∂U( K(x,t,U)*∂U/∂x )/∂x + V(x,t,U)*∂U/∂x + F(x,t,U)
```
where U = U(x,t) is the unknown function (temperature, concentration, etc)
### Solution of hyperbolic equations of the form:
```
M(x,t,U)*∂²U/∂t² = ∂U( K(x,t,U)*∂U/∂x )/∂x + V(x,t,U)*∂U/∂x + F(x,t,U)
```
where U = U(x,t) is the unknown function (displacement of string, etc)
### Support for various boundary conditions:
- Dirichlet (function value at the boundary)
- Neumann (derivative value at the boundary)
- Robin (linear combination of function value and its derivative)
### Efficient numerical methods:
- Finite difference method for derivative approximation
- Thomas algorithm for solving tridiagonal systems of linear equations
## Prerequisites
- JDK 21
- Gradle (embedded in the project)
## Building the project
```bash
./gradlew clean build
```
## Generating documentation
```bash
./gradlew clean javadoc
```
Check `./build/docs/javadoc` folder
Online documentation is available [here](https://andrei-punko.github.io/pde-solvers/)
## Supported equation types
### Parabolic equations
[ParabolicEquation class](src/main/java/io/github/andreipunko/math/pde/equation/ParabolicEquation.java)
- Describes diffusion, heat conduction, and other dissipative processes
- Characterized by the presence of only first-order time derivative
- Solution is defined on the space-time domain `[x1,x2]×[0,t2]`
### Hyperbolic equations
[HyperbolicEquation class](src/main/java/io/github/andreipunko/math/pde/equation/HyperbolicEquation.java)
- Describes wave processes and oscillations
- Characterized by the presence of second-order time derivative
- Solution is defined on the space-time domain `[x1,x2]×[0,t2]`
## Boundary conditions
### Dirichlet (definite mode)
[DirichletBorderCondition class](src/main/java/io/github/andreipunko/math/pde/border/DirichletBorderCondition.java)
- Specifies function value at the boundary: `U(x1,t) = g1(t)` or `U(x2,t) = g2(t)`
### Neumann (definite force)
[NeumannBorderCondition class](src/main/java/io/github/andreipunko/math/pde/border/NeumannBorderCondition.java)
- Specifies derivative value at the boundary: `∂U/∂x(x1,t) = g1(t)` or `∂U/∂x(x2,t) = g2(t)`
### Robin (elastic fixing)
[RobinBorderCondition class](src/main/java/io/github/andreipunko/math/pde/border/RobinBorderCondition.java)
- Specifies linear combination of function value and its derivative:
`∂U/∂x(x1,t) = h*(U(x1,t) - Theta(t))` or
`∂U/∂x(x2,t) = h*(U(x2,t) - Theta(t))`
## Solution methods
### Finite difference method
- Approximates derivatives using finite differences
- Transforms PDE into a system of linear equations
- Uses the Thomas algorithm to solve the resulting system
### Thomas algorithm
- Efficient algorithm for solving tridiagonal systems of linear equations
- Time complexity O(n), where n is the system size
## Time step and spatial step (stability)
The library checks only that `h` and `tau` are finite and positive. It does **not** enforce CFL-type or other
problem-specific stability conditions. The parabolic and hyperbolic schemes here are **implicit**, which usually
improves stability compared to explicit methods, but **accuracy** still depends on resolving the relevant scales:
choose `h` and `tau` using your physics or standard numerical PDE references. If a tridiagonal system at a time step
becomes singular or nearly singular, `IllegalArgumentException` may be thrown from the Thomas-algorithm helper.
## Library usage examples
### Parabolic equations
- [Diffusion problem with Dirichlet boundary conditions](src/test/java/io/github/andreipunko/math/pde/solver/ParabolicEquationSolverDDTest.java)
- [Diffusion problem with Neumann boundary conditions](src/test/java/io/github/andreipunko/math/pde/solver/ParabolicEquationSolverNNTest.java)
- [Heat transfer problem with mixed Dirichlet+Robin boundary conditions](src/test/java/io/github/andreipunko/math/pde/solver/ParabolicEquationSolverDRTest.java)
### Hyperbolic equations
- [Wave equation (plucked string) with Dirichlet boundary conditions](src/test/java/io/github/andreipunko/math/pde/solver/HyperbolicEquationSolverDDTest.java)
### Solution utilities
- [Solution data saving and loading](src/test/java/io/github/andreipunko/math/pde/solver/SolutionTest.java)
## How to use library in your project
The **Maven** and **Gradle** snippets below use the latest **stable** version published to Maven Central.
The version in this repository’s `build.gradle` (`version = …`) is the **current development** line
(often a `-SNAPSHOT`) and may differ until the next release.
### Maven
```xml
io.github.andrei-punko
pde-solvers
1.0.4
```
### Gradle
```gradle
implementation 'io.github.andrei-punko:pde-solvers:1.0.4'
```
### Code example
```java
import io.github.andreipunko.math.pde.border.DirichletBorderCondition;
import io.github.andreipunko.math.pde.equation.ParabolicEquation;
import io.github.andreipunko.math.pde.solver.ParabolicEquationSolver;
import io.github.andreipunko.util.FileUtil;
import java.io.IOException;
class ParabolicEquationSolution {
private final double C_MAX = 100.0; // Max concentration
private final double L = 0.001; // Thickness of plate, m
private final double TIME = 1; // Investigated time, sec
private final double D = 1e-9; // Diffusion coefficient
private final double h = L / 100.0; // Space step
private final double tau = TIME / 100.0; // Time step
public void solve() throws IOException {
var diffusionEquation = buildParabolicEquation();
var solution = new ParabolicEquationSolver()
.solve(diffusionEquation, h, tau);
var numericU = solution.gUt(TIME);
FileUtil.save(numericU, "./build/parabolic1-eqn-solution.txt", true);
}
/**
* Parabolic equation definition
*/
private ParabolicEquation buildParabolicEquation() {
var leftBorderCondition = new DirichletBorderCondition();
var rightBorderCondition = new DirichletBorderCondition();
return new ParabolicEquation(0, L, TIME, leftBorderCondition, rightBorderCondition) {
@Override
public double gK(double x, double t, double U) {
return D;
}
@Override
public double gU0(double x) {
return getC0(x);
}
};
}
/**
* Initial concentration profile
*/
private double getC0(double x) {
x /= L;
if (0.4 <= x && x <= 0.5) {
return C_MAX * (10 * x - 4);
}
if (0.5 <= x && x <= 0.6) {
return C_MAX * (-10 * x + 6);
}
return 0;
}
}
```
## Appendix
### Video with project description
[](https://youtu.be/AmPgu9vksTU)
### How to make new library release on GitHub
See [instruction](.github/how-to-make-GH-release.md)
### How to publish artifact to Maven Central
See [instruction](MAVEN_CENTRAL_PUBLISHING.md)
