# flowview



This plugin allows you to view NetFlow data from inside of Cacti and

to generate Email based reports of the data.



# Features



* Ability to view Flow Data in Table Form or three Chart Forms.

* Parallel Query Execution to increase the speed of report generation.

* Support for Shard Query and Horizontal Scaling through use of technologies

  such as MariaDB MaxScale.

* Tracking of IP addresses that do not resolve through DNS by using ARIN's

  whois service.

* Customizable Scheduled Reports.

* Starting with the 4.x version, the ARIA database format will be the default

  for historical raw tables.  The ARIA format is crash safe, and almost

  5x faster than InnoDB.  The live raw table will always be InnoDB to support

  multiple concurrent inserts, but once that table ages out, it will be

  converted to the ARIA engine by default.

* Starting with the 4.x version, the DNS cache will be manageable.  Therefore,

  if you have intermittant DNS resolution issues, you will be able to view

  and manage those entries in the cache.

* Starting with the 4.x version, you will be able to define a custom unregistered

  domain for local network IP addresses.  This is intended for home users who

  are just trying to see what type of activity is going on on their home

  network.

* Two partitioning methods for raw tables including Hourly and Daily partitioning.

  For larger commercial type deployments, using Hourly partitioning is going

  to be recommended.

* Starting with the 4.x version, sharding results will be cache to increase

  subsequent queries by various users under various conditions.



# Watch our video on YouTube!



[![Video ](http://img.youtube.com/vi/Kic-nY-RThA/0.jpg)](https://youtu.be/Kic-nY-RThA "Flowview Video")



# Installation



To install the plugin, simply copy the plugin_flowview directory to Cacti's plugins

directory and rename it to simply 'flowview'.



Copy config.php.dist to config.php and set the correct db connection.  The

Flowview plugin supports using the Cacti database or a third party database

as the Flowview database can becomee very large over time and may have

differing scalability requirements.



Once this is complete, go to Cacti's Plugin Management section, and Install

and Enable the plugin.



There are a number of settings that are important that you can find under

Console > Configuration > Settings > Flowview.



The minimum version of Cacti required for this plugin will be Cacti 1.2.27.

However, you will have to install the patch to Cacti's database API in this

commit: c11405e584c012f675fb420acf78bcecc7d02d9f.



If you are running an older version of Cacti, you may run Flowview, but you

will not be able to leverage the MaxScale Shard Query feature.



If you are wanting to take advantage of the Shard Query implementation of

Flowview, you must setup your Database so that it replicates itself to

from one to many slave servers.  Then,  you must setup MaxScale.  Note that

MaxScale is under a BSL license.  Therefore, if you wish to scale beyond

two servers, in a commercial setting, you will need to reach out to MariaDB.com

to obtain a license.



You can find real good tutorials at the following links.  Some of the information

may be out-dated in these links.  For example, the backup is super fast when

using the --parallel=X option, but the location of the file with the GTID of

the master has changed, and the format has changed slightly in the 11.x version

of MariaDB.  Additionally, you have to add additional grants for both MaxScale

and MaxScale Monitoring that the tutorials do not fully call out.



If found that the best way to setup a replica was to use mariabackup using the

options that they called out in the documentation.  It really simplifies the

setup.



* MariaDB Replication Setup:

https://mariadb.com/kb/en/setting-up-a-replica-with-mariabackup/

* MariaDB Backup and Restore for Replication Setup:

https://mariadb.com/kb/en/full-backup-and-restore-with-mariabackup/

* MaxScale Setup:

https://mariadb.com/kb/en/maxscale-24-02tutorials/

* MariaDB SSL Setup: (No longer required as of MariaDB 11.3)

https://mariadb.com/resources/blog/mariadb-maxscale-2-1-and-ssl-certificates/



## Required:



Before you start, with this version of Flowview, you have to ensure that you are

at MariaDB 10.5 or above.  Cacti has been shown to support MariaDB upto 11.4.x.

MySQL 8.0+ is required. Unfortunatly, MySQL does not support Aria Tables and will

therfore have lower performance than MariaDB for scanning data.



Then, Install flowview just like any other plugin, just copy it into the plugin

directory, and Use Console > Plugin Management to Install and Enable.



This version of the flowview plugin no longer requires flowtools or

OpenFlashCharts.  In fact the entire import and reporting process is handled

through php and uses JavaScript based charting already available in Cacti.



Note that additionally, you must install the Linux utility `ss` if it is

not already installed.  Netstat will help Cacti determine if the `flow-capture`

service in question is actually running.



After installing, you should set your partitioning and retention settings from

Console > Configuration > Settings > Flowview.  There is a flowview section there

that you can customize.



Next you have to setup your Cacti server as a Flowview sink from your various

sources.  Then, from Flowview > Listeners, you must add the various listeners

for all your flow-capture sources.  It's critical that you specify the correct

port, and if there is to be any filtering, having a value other than 0 for the

allowed devices.



You must then setup the init.d or systemd service to receive captured data and

transfer into the Cacti database.  Check the README.md in the service folder to

describe this process.  Any time you add a new listener, you must restart this

service.



## System Tuning



You may be required to increase some system defaults such a max connections

and UDP buffering to achieve high performance.  See your operating systems

documentation on the use of the sysctl to increase somaxconn and your

max udp buffer space.  You can store your changes in /etc/sysctl.d/cacti.conf.



## Automatic Flow Version Detection:



The new Cacti based flow-capture script will auto-detect either V5, V9 or IPFIX

flows automatically.  So, can dynamically switch these streams versions without

issue and you can have multiple streams coming into the same port at the same

time.  However, we recommend you have you watch the CPU utilization of the

flow collector processes, and if they start consuming near 100% utilization,

you should add more listeners to spread the load.



## Automatic Domain Resolution:



The flow-capture script will receive the flow data, and attempt to resolve the

domain names of the flows.  In the case that an IP Address does not properly

resolve to a domain, Cacti automatically queries IANA to find the owner and

assigned as 'assumed' domain for those flows.  If your Cacti server can not

reach IANA, then those IP's will simply not be resolved.



## Upgrading from Prior Versions



Since the current release does not leverage flow-capture, you will need to

migrate your existing flow data into the Cacti database.  Before you perform

this migration, ensure that your Cacti system, has enough space to handle all

the flow data.  You should check the size of your existing flows, and then

verify that you have enough space to handle the data inside of a MySQL database.



Once you have done this, simply run the 'import_flows.php' script and all your

legacy flow data will be imported.  Remember, it's important that you define

your partitioning scheme ahead of time, especially if you have large quantities

of flow data streaming into the Cacti server.



# Possible Bugs?



If you figure out this problem, goto GitHub and create a pulls request or open

an issue.



# Future Changes



Got any ideas or complaints, please see the Cacti forums or GitHub for a

resolution.



-----------------------------------------------

Copyright (c) 2004-2024 - The Cacti Group, Inc.
