# Traefik Manager

**A clean, self-hosted web UI for managing your Traefik reverse proxy.**

Add routes, manage middlewares, monitor services, and view TLS certificates - all without touching a YAML file by hand.

[![Docker Image](https://img.shields.io/badge/ghcr.io-chr0nzz%2Ftraefik--manager-blue?logo=docker&logoColor=white)](https://github.com/chr0nzz/traefik-manager/pkgs/container/traefik-manager)

[![License](https://img.shields.io/badge/license-GPL--3.0-blue)](LICENSE)

[![Version](https://img.shields.io/github/v/release/chr0nzz/traefik-manager)](https://github.com/chr0nzz/traefik-manager/releases)

[![Docs](https://img.shields.io/badge/docs-github.io-blue)](https://traefik-manager.xyzlab.dev/)

[![Mobile App](https://img.shields.io/badge/mobile-repo-green?logo=android&logoColor=white)](https://github.com/chr0nzz/traefik-manager-mobile)

[![Google Play](https://img.shields.io/badge/Google_Play-Available-blue?logo=google-play&logoColor=white)](https://play.google.com/store/apps/details?id=dev.chr0nzz.traefikmanager)

[![Ko-fi](https://img.shields.io/badge/Ko--fi-Sponsor-ff5f5f?logo=ko-fi&logoColor=white)](https://ko-fi.com/chr0nzz)





Built for homelabbers who love Traefik but hate editing YAML at 2am.



---

## Interface Gallery

Initial Setup Workflow










1. Login










2. Welcome










3. Connection & domains










4. Self route










5. Optional tabs










6. Set password

Dashboard













Routes










Card View










List View










Add HTTP










Add TCP










Add UDP

Services





















Middlewares










Card View










List View










Add

Plugins





















Route Map













Settings










Interface










Authentication










API Keys










Static Config










Connection










Backups

---

## Features

**Routing & Middleware**

- Add, edit, delete, and **enable/disable** HTTP, TCP, and UDP routes - no YAML editing required

- **Advanced rule editor** - toggle between a domain chip builder and a free-text rule input for complex expressions (`PathPrefix`, `HostRegexp`, `&&` / `||` compounds, etc.)

- **Multiple domains per route** - select any combination of your configured domains; generates multi-host Traefik rules (`Host(\`sub.d1\`) || Host(\`sub.d2\`)`)

- **Per-service insecureSkipVerify** - checkbox adds a named `serversTransport` for backends with self-signed certs (Proxmox, Kasm, etc.); yellow TLS skip badge shown on route cards

- **Wildcard certificate domains** - "Request wildcard certificate" checkbox auto-fills `tls.domains` from the selected domain; use with DNS challenge resolvers to request `*.domain.com` certs

- **TLS Options tab** - create and manage named `tls.options` profiles (min/max version, cipher suites, curve preferences, SNI strict, ALPN, mTLS client auth); assign a profile to any route via the route form

- **23 middleware wizard templates** with guided form fields (Basic Auth, Forward Auth, Rate Limit, IP Allowlist, Secure Headers, CORS, Redirect, Strip/Add Prefix, Retry, Circuit Breaker, Buffering, and more) - toggle to raw YAML for anything else

- **Route clone** - duplicate a route into the add modal pre-filled with its service URL, middlewares, and entrypoints

- **Multi-config file support** - mount several dynamic config files with `CONFIG_DIR` or `CONFIG_PATHS`; a dropdown selects which file each route or middleware is saved to; **create new files on the fly** when `CONFIG_DIR` is set

- **Timestamped backups** before every change; one-click restore from Settings; `POST /api/backup/create` and `POST /api/backup/static/create` for automation

- **Git Repository Backup** - push your Traefik configuration to a remote Git repository (GitHub, Gitea, Forgejo, GitLab, or any HTTPS host) after every change; browse the full commit history, view per-file side-by-side diffs, and restore any commit with one click; access token stored encrypted at rest; auto-push on every route, middleware, or static config save; manual push and Test Connection available in Settings → Backups → Git

**Live Dashboard**

- Real-time stats: router counts, service health, entrypoints, Traefik version

- Provider tabs: Docker, Kubernetes, Swarm, Nomad, ECS, Consul Catalog, Redis, etcd, Consul KV, ZooKeeper, HTTP Provider, File - all API-based, no extra mounts; **each tab shows provider middlewares** in a read-only section

- **Filter live services** by protocol (HTTP/TCP/UDP) and provider (docker, file, kubernetes…)

- **List view toggle** on Routes, Middlewares, and Services tabs - switch between card grid and compact table

**Visualizations** *(optional, toggle in Settings)*

- **Dashboard tab** - routes grouped by category (Media, Monitoring, Infrastructure, etc.) with app icons sourced from [selfh.st/icons](https://selfh.st/icons/), cached locally, and per-card editing (display name, icon override, group override)

- **Route Map tab** - 4-column topology view (Entry Points - Routes - Middlewares - Services) with Bezier curve connections, hover-to-highlight, and route tooltips

**Static Config Editor** *(optional - mount `traefik.yml` read-write)*

- Edit Traefik's static configuration directly from the UI - entrypoints, certificate resolvers, plugins, and a raw YAML editor (Monaco/VS Code engine) for anything else

- Changes are staged with a pending banner, backed up before saving, and Traefik is restarted automatically

- Three restart methods: **socket proxy** (recommended - sidecar with minimal socket exposure), **poison pill** (no socket needed - shared signal file), **direct socket**

- Full-screen reconnect overlay polls until Traefik is back up and dismisses automatically

**System Monitoring** *(optional)*

- **Certs** - `acme.json` certificates with expiry tracking

- **Plugins** - plugins from your static `traefik.yml`; add, edit, and remove plugins when static config editor is enabled

- **Logs** - parsed access log cards showing method, status, path, IP, service, and duration; click any card for a full detail panel with all fields and the raw log line

- **CrowdSec** - active decisions and recent alerts from a CrowdSec LAPI; add manual bans/captchas/bypasses or unban IPs with one click; stats cards show total alerts, active decisions, LAPI status, and type breakdown. Configure via `CROWDSEC_LAPI_URL` / `CROWDSEC_API_KEY` env vars or **Settings → System Monitoring → CrowdSec**

- **Configurable file paths** - set `acme.json`, access log, and static config paths from **Settings → File Paths** without a container restart; UI setting takes priority over env vars

**Multi-Server Management**

- **Traefik Manager Agent (TMA)** - lightweight Go daemon that runs alongside Traefik on any remote server; install it in seconds with the one-liner installer

- **Server switcher** in the nav bar - switch between local and remote agents; all data tabs show that server's routes, services, middlewares, backups, and logs

- **Settings → Agents** multi-step wizard - generates a ready-to-paste Docker Compose or Docker Run command with all env vars pre-filled; API key shown once and stored encrypted

- **Per-server git backup** - each agent handles its own autonomous git cycle via env vars; viewed from TM when that agent is active

- Manage unlimited remote Traefik instances from a single TM - no VPN or SSH required

**Security**

- bcrypt passwords (cost 12), CSRF protection, session management with session fixation protection

- Optional TOTP 2FA · 7-day remember me · configurable inactivity timeout

- Auto-generated password on first start · CLI recovery with `flask reset-password`

- **OIDC / SSO** - sign in with Keycloak, Google, Authentik, or any OIDC-compliant provider alongside password login; access restricted to specific emails or groups; client secret stored encrypted at rest

- **Per-device API keys** - up to 10 named keys (e.g. "My Phone"), each independently revocable via `X-Api-Key` header

- **Traefik API basic auth** - set `TRAEFIK_API_USER` / `TRAEFIK_API_PASSWORD` (or via Settings) for Traefik dashboards with `api.insecure: false`

- **Rate limiting** on login and auth endpoints (Flask-Limiter)

- **Atomic config writes** - crash-safe YAML saves via temp file + rename

- **Encrypted OTP secret** - TOTP seed encrypted at rest with Fernet

---

## Mobile App

**traefik-manager-mobile** is a React Native companion app for managing Traefik Manager from your phone. Requires **Traefik Manager v1.0.0 or higher**.

|          |                                                                                                |

| ----------| ------------------------------------------------------------------------------------------------|

| Repo     | [github.com/chr0nzz/traefik-manager-mobile](https://github.com/chr0nzz/traefik-manager-mobile) |

| Download | [Latest release](https://github.com/chr0nzz/traefik-manager-mobile/releases/latest)            |

| Auth     | Per-device API key - generate one in **Settings → Authentication → App / Mobile API Keys**     |







Features: browse routes, middlewares, and services · enable/disable routes · add and edit routes and middlewares (23 middleware templates with guided wizards) · multiple domains per route · per-service insecureSkipVerify · backend scheme + pass host header controls · multi-config file picker · edit mode for bulk actions · CrowdSec tab · system light/dark theme.

---

## Quick Start

**One-liner installer** - installs Traefik + Traefik Manager together, or Traefik Manager on its own via Docker or a native Linux service:

```bash

curl -fsSL https://get-traefik.xyzlab.dev | bash

```

**Manual Docker Compose:**

```yaml

services:

  traefik-manager:

    image: ghcr.io/chr0nzz/traefik-manager:latest

    container_name: traefik-manager

    restart: unless-stopped

    ports:

      - "5000:5000"

    environment:

      - COOKIE_SECURE=false

    volumes:

      - /path/to/traefik/dynamic.yml:/app/config/dynamic.yml

      - /path/to/traefik-manager/config:/app/config

      - /path/to/traefik-manager/backups:/app/backups

```

```bash

docker compose up -d

```

Open **http://your-server:5000** - the setup wizard will guide you through the rest.

---

## Deployment

| Runtime                                                                                                              | Guide                                                                                                                 |

| ----------------------------------------------------------------------------------------------------------------------| -----------------------------------------------------------------------------------------------------------------------|

|  Installer | [One-liner: full stack, TM-only Docker, TM-only Linux service, Agent](https://traefik-manager.xyzlab.dev/traefik-stack.html) |

|  Docker              | [Docker Compose setup, networking, behind Traefik](https://traefik-manager.xyzlab.dev/docker.html)                    |

|  Podman              | [Rootless, Quadlet/systemd, SELinux labels](https://traefik-manager.xyzlab.dev/podman.html)                           |

|  Linux                | [Native Python + systemd, no container required](https://traefik-manager.xyzlab.dev/linux.html)                       |

|  Unraid              | [Community Applications template, networking, multi-config](https://traefik-manager.xyzlab.dev/unraid.html)           |

| Agent                                                                                                         | [TMA - remote agent for multi-server management](https://traefik-manager.xyzlab.dev/agent.html)                       |

---

## Documentation

Full documentation at **[traefik-manager.xyzlab.dev](https://traefik-manager.xyzlab.dev/)**

|                                                                           |                                                       |

| ---------------------------------------------------------------------------| -------------------------------------------------------|

| [Get Started](https://traefik-manager.xyzlab.dev/guide.html)              | Deployment guides for Docker, Podman, and Linux       |

| [Traefik Stack](https://traefik-manager.xyzlab.dev/traefik-stack.html)    | One-liner installer guide                             |

| [Configuration](https://traefik-manager.xyzlab.dev/manager-yml.html)      | `manager.yml` reference                               |

| [Environment Variables](https://traefik-manager.xyzlab.dev/env-vars.html) | `CONFIG_DIR`, `CONFIG_PATHS`, auth, domains, and more |

| [Security](https://traefik-manager.xyzlab.dev/security.html)              | API keys, sessions, CSRF, rate limits, and hardening  |

| [API Reference](https://traefik-manager.xyzlab.dev/api.html)              | REST API for integrations and the mobile app          |

| [OIDC / SSO](https://traefik-manager.xyzlab.dev/oidc.html)                | OIDC setup, provider examples, and access control     |

| [Git Repository Backup](https://traefik-manager.xyzlab.dev/git-backup.html) | Auto-push, commit history, diff viewer, and one-click restore |

| [Mobile App](https://traefik-manager.xyzlab.dev/mobile.html)              | Android companion app setup and features              |

| [Reset Password](https://traefik-manager.xyzlab.dev/reset-password.html)  | CLI reset, TOTP recovery, manual reset                |

| [UI Examples](https://traefik-manager.xyzlab.dev/ui-examples.html)        | Screenshots and walkthroughs                          |

| [Provider Tabs](https://traefik-manager.xyzlab.dev/tab-docker.html)                      | Docker, Kubernetes, Swarm, Nomad, ECS, and more       |

---

## Tech Stack

| Layer     | Technology                                    |

| -----------| -----------------------------------------------|

| Backend   | Python 3.11 · Flask · Gunicorn                |

| Agent     | Go 1.23 · Alpine Linux (TMA - remote agent daemon) |

| Config    | ruamel.yaml (preserves comments)              |

| Auth      | bcrypt · pyotp (TOTP) · Flask sessions · CSRF · Flask-Limiter · Fernet |

| Frontend  | Vanilla JS · Tailwind CSS · Phosphor Icons    |

| Editor    | Monaco Editor (VS Code engine)                |

| Route Map | dagre (graph layout)                          |

| Container | Docker · Alpine Linux · all JS/CSS dependencies bundled at build time (no CDN at runtime) |

---

## Contributing

Pull requests are welcome. See [CONTRIBUTING.md](CONTRIBUTING.md) for how to report bugs, suggest features, and run the project locally.

## Star History















## License

[GPL-3.0](LICENSE)
