# Multilabel Movie Poster Classification
Multilabel image classification to classify movie poster and find appropriate movie genre with movie poster. For this project **tensorflow** framwork is used for deep learning model. The model is converted into **tf lite** to reduce final model size. This is a complete project with server side code and also fronted. To deploy deep learning model, **flask** is used and deployed into **heroku** server. By using **Flutter** framework frontend web app is developed and deployed into **firebase**.
**Notebook**: [Click here](https://github.com/Iamsdt/MultilabelMoviePosterClassification/blob/master/notebook/Multilabel_Image.ipynb)
**Web App**: [Movie Poster Classifier](https://flutter-web-3a021.firebaseapp.com/#/)
## AI model
Framework: Tensorflow 2.1
Datasets: [Movie_Poster_Dataset](https://www.cs.ccu.edu.tw/~wtchu/projects/MoviePoster/Movie_Poster_Dataset.zip)
### Classifier Architecture
**Input Shape**: (350, 350, 3)
**Label**: (24)
**Output Shape**: (24)
**Model Summary**
```
Model: "sequential"
_________________________________________________________________
Layer (type) Output Shape Param #
=================================================================
conv2d (Conv2D) (None, 348, 348, 16) 448
_________________________________________________________________
batch_normalization (BatchNo (None, 348, 348, 16) 64
_________________________________________________________________
dropout (Dropout) (None, 348, 348, 16) 0
_________________________________________________________________
conv2d_1 (Conv2D) (None, 346, 346, 32) 4640
_________________________________________________________________
batch_normalization_1 (Batch (None, 346, 346, 32) 128
_________________________________________________________________
max_pooling2d (MaxPooling2D) (None, 173, 173, 32) 0
_________________________________________________________________
dropout_1 (Dropout) (None, 173, 173, 32) 0
_________________________________________________________________
conv2d_2 (Conv2D) (None, 171, 171, 64) 18496
_________________________________________________________________
batch_normalization_2 (Batch (None, 171, 171, 64) 256
_________________________________________________________________
max_pooling2d_1 (MaxPooling2 (None, 85, 85, 64) 0
_________________________________________________________________
dropout_2 (Dropout) (None, 85, 85, 64) 0
_________________________________________________________________
conv2d_3 (Conv2D) (None, 83, 83, 128) 73856
_________________________________________________________________
batch_normalization_3 (Batch (None, 83, 83, 128) 512
_________________________________________________________________
max_pooling2d_2 (MaxPooling2 (None, 41, 41, 128) 0
_________________________________________________________________
dropout_3 (Dropout) (None, 41, 41, 128) 0
_________________________________________________________________
flatten (Flatten) (None, 215168) 0
_________________________________________________________________
dense (Dense) (None, 128) 27541632
_________________________________________________________________
batch_normalization_4 (Batch (None, 128) 512
_________________________________________________________________
dropout_4 (Dropout) (None, 128) 0
_________________________________________________________________
dense_1 (Dense) (None, 128) 16512
_________________________________________________________________
batch_normalization_5 (Batch (None, 128) 512
_________________________________________________________________
dropout_5 (Dropout) (None, 128) 0
_________________________________________________________________
dense_2 (Dense) (None, 24) 3096
=================================================================
Total params: 27,660,664
Trainable params: 27,659,672
Non-trainable params: 992
```
### Hyperparameters
| Parameters | |
| ------------- | ------------------- |
| Optimizer | Adam |
| Learning rate | 0.001 |
| Loss function | Binary Crossentropy |
| Batch size | 32 |
| Epoch | 5 |
### Training Logs
```
Train on 6854 samples, validate on 1210 samples
Epoch 1/5
6854/6854 [==============================] - 39s 6ms/sample - loss: 0.6711 - accuracy: 0.6647 - val_loss: 0.3302 - val_accuracy: 0.9021
Epoch 2/5
6854/6854 [==============================] - 34s 5ms/sample - loss: 0.3010 - accuracy: 0.8932 - val_loss: 0.2634 - val_accuracy: 0.9020
Epoch 3/5
6854/6854 [==============================] - 34s 5ms/sample - loss: 0.2676 - accuracy: 0.9039 - val_loss: 0.2620 - val_accuracy: 0.9027
Epoch 4/5
6854/6854 [==============================] - 34s 5ms/sample - loss: 0.2602 - accuracy: 0.9062 - val_loss: 0.2636 - val_accuracy: 0.9030
Epoch 5/5
6854/6854 [==============================] - 34s 5ms/sample - loss: 0.2555 - accuracy: 0.9072 - val_loss: 0.2640 - val_accuracy: 0.9030
```
### Loss & Accuracy Graph
### Output
### Model Conversion
Tensor flow model is converted into tf.lite. The main model size is 350 mb+, after convert into tf lite the final size ~ 55 mb+.
```python
converter = tf.lite.TFLiteConverter.from_keras_model(net)
tflite_model = converter.convert()
```
This conversion reduce model size into ~110 mb.
Next, Float32 converted into Float 16.
```
converter.optimizations = [tf.lite.Optimize.DEFAULT]
converter.target_spec.supported_types = [tf.float16]
tflite_fp16_model = converter.convert()
```
And saved optimized model
```
tflite_model_fp16_file = tflite_models_dir/"movie_optimized.tflite"
tflite_model_fp16_file.write_bytes(tflite_fp16_model)
```
Now model size is 55.00 mb
Compare outputs between 3 models (tensorflow model, tflite model, tflite optimized model)
```
Output from tensorflow model:, War, Action, News
Output from tensorflow lite model:, War, Action, News
Output from tensorflow lite optimized model:, War, Action, News
```
### Notebook link: [Click here](https://github.com/Iamsdt/MultilabelMoviePosterClassification/blob/master/notebook/Multilabel_Image.ipynb)
## Web Server
For deploying model **Flask** is used
Used libraries
```
tensorflow
numpy
Flask==1.1.1
gunicorn==20.0.4
Pillow
flask-cors
```
Server accept **post** request with image bytes as data and return the predicted values in **json** format.
```
@app.route('/analysis/', methods=['POST', 'GET'])
def analysis():
if request.method == 'POST':
img = request.data
response = predict(img)
data = {
"result": response
}
return jsonify(
data)
```
#### Server link: https://rocky-beyond-88001.herokuapp.com/analysis
## Webapp
For frontend web app, **Flutter web framework** is used
### Flutter Version:
**Flutter 1.15.19**
**Dart 2.8.0**
### Used Libraries
```
http: ^0.12.0+4
html: ^0.14.0+3
retrofit: ^1.3.1+1
logger: ^0.8.3
states_rebuilder: ^1.14.2
json_annotation: ^3.0.1
url_launcher: ^5.4.2
```
Website deployed in **Firebase**
#### Web app link: [Movie Poster Classifier](https://flutter-web-3a021.firebaseapp.com/#/)
### Web App Screenshot
## Want to run locally?
Clone this repo
```
git clone https://github.com/Iamsdt/MultilabelMoviePosterClassification.git
```
For **AI model** see this notebook, [click here](https://github.com/Iamsdt/MultilabelMoviePosterClassification/blob/master/notebook/Multilabel_Image.ipynb)
**Server side code**: all the server side code including model file located into **server** folder
**Flutter Web App**: Located into **app/web_app**
Open in the IDE with flutter plugin and run this command, to generate
```
flutter run -d chrome
```
Note: you need chorme web browser to run locally.
