https://github.com/isuckatcs/how-to-compile-your-language
An introduction to language design with building a compiler frontend on top of LLVM.
https://github.com/isuckatcs/how-to-compile-your-language
compiler-design compiler-frontend compilers cpp educational-materials languages llvm
Last synced: 6 days ago
JSON representation
An introduction to language design with building a compiler frontend on top of LLVM.
- Host: GitHub
- URL: https://github.com/isuckatcs/how-to-compile-your-language
- Owner: isuckatcs
- Created: 2024-05-28T00:10:27.000Z (6 months ago)
- Default Branch: main
- Last Pushed: 2024-08-08T14:02:42.000Z (3 months ago)
- Last Synced: 2024-10-31T04:03:26.581Z (20 days ago)
- Topics: compiler-design, compiler-frontend, compilers, cpp, educational-materials, languages, llvm
- Language: HTML
- Homepage: https://isuckatcs.github.io/how-to-compile-your-language/
- Size: 1.17 MB
- Stars: 89
- Watchers: 4
- Forks: 13
- Open Issues: 0
-
Metadata Files:
- Readme: README.MD
Awesome Lists containing this project
README
![cover](https://isuckatcs.github.io/how-to-compile-your-language/img/cover.png)
A simple programming language implementation with an educational guide that displays modern compiler techniques.
[isuckatcs.github.io/how-to-compile-your-language](https://isuckatcs.github.io/how-to-compile-your-language/)
## Getting Started
This guide assumes that the project is being built on Linux* but equivalent steps can be performed on any other operating system.
1. Install CMake 3.20 or newer
- `apt-get install cmake`2. Install LLVM and Clang
- The project was originally built for **LLVM 14.0.0**. Other versions are not guaranteed to work.
- `apt-get install llvm clang`3. Create a build directory and enter that directory
- `mkdir build && cd build`4. Configure CMake and build the project
- `cmake path/to/repo/root && cmake --build .`To run the tests, proceed with these following optional steps.
5. Install Python 3.10 or newer
- `apt-get install python`6. Install the required dependencies
- `pip install -r ./test/requirements.txt`7. Run the `check` target with CMake
- `cmake --build . --target check`\* tested on Ubuntu 22.04.3 LTS
## Features
### Clean SyntaxUnambiguous, modern and easy to parse syntax with elements inspired by C, Kotlin, Rust and Swift.
```
fn main(): void {
println(0);
}
```### Static Type System
Simple type system currently supporting the `number` and `void` types with the capability to be expanded by user-defined types.
The `number` type is implemented as a 64-bit floating point value.
```
fn main(): void {
let x: number = 1234;
let y: number = 12.34;
}
```### Lazy Initialization
Data-flow analysis based support for detecting lazily initialized and uninitialized variables.
```
fn dataFlowAnalysis(n: number): void {
let uninit: number;if n > 3 {
uninit = 1;
}println(uninit);
}
```
```
main.yl:8:13: error: 'uninit' is not initialized
```### Naive Type Inference
When a variable is initialized, the type specifier can be omitted as the type is inferred from the initializer.```
fn main(): void {
let typeInference = 1;
}
```### Immutability
Immutable and mutable variables declared with the `let` and `var` keywords.
```
fn main(): void {
let immutable = 1;
var mutable = 2;while mutable > 2 {
immutable = 0;
mutable = mutable - 1;
}
}
```
```
main.yl:6:7: error: 'immutable' cannot be mutated
```### Compile Time Expression Evaluation
Expressions are evaluated by a tree-walk interpreter during compilation if possible.
```
fn main(): void {
let x = (1 + 2) * 3 - -4;
println(x);
}
```
```
$ compiler main.yl -res-dumpResolvedFunctionDecl: @(main.addr) main:
ResolvedBlock
...
ResolvedCallExpr: @(println.addr) println
ResolvedDeclRefExpr: @(x.addr) x
| value: 13
```### Smart Return Check
Flow-sensitive return value analysis made smarter with compile time expression evaluation.
```
fn maybeReturns(n: number): number {
if n > 2 {
return 1;
} else if n < -2 {
return -1;
}// missing return 'else' branch
}fn alwaysReturns(n: number): number {
if 0 && n > 2 {
// unreachable
} else {
return 0;
}
}
```
```
main.yl:1:1: error: non-void function doesn't return a value on every path
```### Native Code Generation
A source file is first compiled to LLVM IR, which is then passed to the host platform specific LLVM backend to generate a native executable.
```
fn main(): void {
println(1.23);
}
```
```
$ compiler main.yl -o main.out
$ ./main.out
1.23
```### Accessible Internals
Capability to print the Abstract Syntax Tree before and after resolution, the Control-Flow Graph and the generated LLVM IR module.
```
fn main(): void {
println(1.23);
}
```
```
$ compiler main.yl -ast-dumpFunctionDecl: main:void
Block
CallExpr:
DeclRefExpr: println
NumberLiteral: '1.23'
```
```
$ compiler main.yl -res-dumpResolvedFunctionDecl: @(main.addr) main:
ResolvedBlock
ResolvedCallExpr: @(println.addr) println
ResolvedNumberLiteral: '1.23'
| value: 1.23
```
```
$ compiler main.yl -cfg-dumpmain:
[2 (entry)]
preds:
succs: 1[1]
preds: 2
succs: 0
ResolvedNumberLiteral: '1.23'
| value: 1.23
ResolvedCallExpr: @(println.addr) println
ResolvedNumberLiteral: '1.23'
| value: 1.23[0 (exit)]
preds: 1
succs:
```
```
$ compiler main.yl -llvm-dumpdefine void @__builtin_main() {
call void @println(double 1.230000e+00)
ret void
}
```
