# 🚌 Dublin Bus App
**The Dublin Bus App has been built in an attempt to use real time data using the API's provided by the [National Transport Authority](https://developer.nationaltransport.ie/). Using this app you can see the incoming buses for a selected stop and the buses that currently operate a route based on a direction.**
---
## 🧬 **Project Structure**
```bash
DublinBusApp
├── assets/
│ ├── data/
│ │ ├── Routes.txt
│ │ ├── StopMapLocation.txt
│ │ ├── StopTimesPerTrip.txt
│ │ └── Towards.csv
│ ├── dataCleaning/
│ │ ├── 00_EndpointExploration.ipynb
│ │ ├── 01_DataCleaning.ipynb
│ │ ├── 02_Flow_01_⌚_StopTimes.ipynb
│ │ ├── 03_Flow_02_📍_BusLocator.ipynb
│ │ ├── routes.txt
│ │ ├── stop_times.txt
│ │ ├── stops.txt
│ │ └── trips.txt
│ ├── gifs/
│ │ ├── BusLocator.gif
│ │ └── StopTimes.gif
│ └── images/
│ ├── bus.png
│ ├── dublin_bus_favicon.png
│ ├── dublin_bus_logo.png
│ ├── pin_blue.png
│ ├── pin_green.png
│ ├── pin_red.png
│ └── tfi_logo.png
├── streamlit_app/
│ ├── modules/
│ │ ├── __init__.py
│ │ ├── BLutils.py
│ │ ├── DataPrep.py
│ │ ├── STutils.py
│ │ └── Styles.py
│ ├── pages/
│ │ ├── 01_⌚_StopTimes.py
│ │ └── 02_📍_BusLocator.py
│ └── 00_🚌_Info.py
├── LICENSE
├── README.md
└── requirements.txt
```
---
## 🎯 **Road Map**
Plan to develop the app:
- **Understand the data provided by the APIs**
- **Explore the static data provided by the NTA to complement data shown in the APIs**
- **Design the logic for `StopTimes` and `BusLocator` pages**
---
## 🏗️ **Deployment**
1. **Understand the data provided by the APIs**:
- First, sign up for the [National Transport Authority (NTA)](https://developer.nationaltransport.ie/) to access their APIs. Use the following link to sign up: [Sign up here](https://developer.nationaltransport.ie/signup).
- Next, understand and visualise the data provided by the following endpoints:
- [GTFSR Endpoint](https://api.nationaltransport.ie/gtfsr/v2/gtfsr?format=json)
- [Vehicles Endpoint](https://api.nationaltransport.ie/gtfsr/v2/Vehicles?format=json)
- To assist with exploring these endpoints, I have created a Jupyter Notebook (JN): [00_EndpointExploration.ipynb](https://github.com/josericodata/DublinBusApp/blob/main/assets/dataCleaning/00_EndpointExploration.ipynb). Replace `os.environ.get("API_KEY")` with the variable `YOUR_API_KEY`, and you're ready to proceed.
2. **Exploring and Preparing NTA Dublin Bus Static Data**:
- Please head over to the following link: [GTFS Dublin Bus Data](https://www.transportforireland.ie/transitData/Data/GTFS_Dublin_Bus.zip). This will download the file `GTFS_Dublin_Bus.zip`. After downloading, extract the files.
- We will need the following files from the extracted data:
1. `routes.txt`
2. `stops.txt`
3. `stop_times.txt`
4. `trips.txt`
- These files will be used to generate the following new files:
1. `Routes.txt`
2. `StopMapLocation.txt`
3. `StopTimesPerTrip.txt`
4. `Towards.txt`
- To visualise this step, I have created a JN: [01_DataCleaning.ipynb](https://github.com/josericodata/DublinBusApp/blob/main/assets/dataCleaning/01_DataCleaning.ipynb).
- **The files mentioned above were used in the early stages of this project. However, since the NTA updates `GTFS_Dublin_Bus.zip` almost every week, maintaining the app required frequent updates. To simplify this process, I created [DataPrep.py](https://github.com/josericodata/DublinBusApp/blob/main/streamlit_app/modules/DataPrep.py). With this script, every time the app runs, it fetches fresh data from [GTFS Dublin Bus Data](https://www.transportforireland.ie/transitData/Data/GTFS_Dublin_Bus.zip). I am keeping the old `.txt` files in case they help someone better understand this complex process.**
3. **What is GTFS?**
- Summarising point 1 and 2, the **General Transit Feed Specification (GTFS)** is a standardised format for public transportation data, allowing transit agencies to share schedules, routes, and real-time updates. It consists of structured text files that define agencies, stops, routes, trips, and schedules.
🔹 **GTFS Data Types:**
| Type | Description |
|----------------|------------|
| **GTFS Realtime** | Delivers live updates on vehicle positions, delays, and service alerts. Uses `GTFSR` and `Vehicles` endpoints. |
| **GTFS Static** | Provides fixed schedules, routes, and stop locations. Uses `GTFS_Dublin_Bus.zip`. |
- For more details, visit the official GTFS website: [GTFS.org](https://gtfs.org/)
4. **Logic Design for `StopTimes` and `BusLocator` Pages**:
- After understanding the data provided by the endpoints and the static files, it is time to develop the logic for the pages.
- **`StopTimes` Page**:
- The user will first select a `route`, then be prompted to choose a `direction`, and finally select a `stop` to display the buses that are due to arrive.
- For a clear understanding of this flow, refer to the JN: [02_Flow_01_⌚_StopTimes.ipynb](https://github.com/josericodata/DublinBusApp/blob/main/assets/dataCleaning/02_Flow_01_⌚_StopTimes.ipynb).
- **`BusLocator` Page**:
- This page will show the operating buses for the selected `route` and `direction`.
- For more details on this logic, refer to the JN: [03_Flow_02_📍_BusLocator.ipynb](https://github.com/josericodata/DublinBusApp/blob/main/assets/dataCleaning/03_Flow_02_📍_BusLocator.ipynb).
---
5. **Streamlit App Creation**:
- After completing the steps above, the final app can be found at: [streamlit_app](https://github.com/josericodata/DublinBusApp/tree/main/streamlit_app).
## 🚀 **Getting Started**
### **Local Installation**
1. Clone the repository:
```bash
git clone https://github.com/user/DublinBusApp.git
```
**Hint:** Replace `user` with `josericodata` in the URL above. I am deliberately asking you to pause here so you can support my work. If you appreciate it, please consider giving the repository a star or forking it. Your support means a lot—thank you! 😊
2. Navigate to the project directory:
```bash
cd DublinBusApp
```
3. Create a virtual environment:
```bash
python3 -m venv venvDublinBus
```
4. Activate the virtual environment:
```bash
source venvDublinBus/bin/activate
```
5. Install requirements:
```bash
pip install -r requirements.txt
```
6. Navigate to the modules directory:
```bash
cd streamlit_app/modules
```
7. Please locate in `BLutils.py` and `STutils.py` the following line code:
```bash
YOUR_API_KEY = st.secrets["API_KEY"]
```
It is crutial to replace `st.secrets["API_KEY"]` with the actual API Key provided by the [National Transport Authority](https://developer.nationaltransport.ie/) after [signing up](https://developer.nationaltransport.ie/signup) to acces their APIs. Please use the following link to sign up: https://developer.nationaltransport.ie/signup
8. Go back one directory and run the app:
```bash
cd ..
```
Then run
```bash
streamlit run 00_🚌_Info.py
```
The app will be live at `http://localhost:8501`.
---
## 🎬 **Demo**
### Page 1: Stop Times
### Page 2: Bus Locator
---
### ▶️ Watch the YouTube Tutorial
[](https://www.youtube.com/watch?v=PaU5KaZCJ5E "Click to play")
Click the image above or [here](https://www.youtube.com/watch?v=PaU5KaZCJ5E) to watch the video on YouTube.
---
## 🔮 **Future Enhancements**
Planned improvements for the Dublin Bus App include:
- **Database Integration**: Implementing a relational database (e.g., PostgreSQL) to better manage and query data, enabling faster performance and enhanced data relationships between routes, stops, and trips.
- **Historical Data Storage**: Storing historical bus data to provide insights like delay trends, busiest stops, and more accurate arrival time predictions using machine learning.
- **Personalised Features**: Adding user-specific data storage, such as favorite routes or frequently accessed stops, for a more tailored experience.
- **Advanced Reporting and Analytics**: Generating detailed reports, such as route popularity or stop traffic trends, with visualisations like heatmaps or charts.
- **Enhanced Pages**: Introducing new pages and features, including route performance tracking, user feedback collection, and real-time bus location improvements.
- **Scalability**: Preparing the app for multi-user support by efficiently handling concurrent queries through the database.
---
## 🎓 **Motivation**
- The motivation behind developing this app is to gain hands-on experience in working with JSON-formatted data from real-time APIs. As a resident of Ireland, I found Dublin Bus data particularly convenient, as I am familiar with many of the routes, buses, and stops.
- Additionally, this project helps me stay up to date with my skills while serving as a valuable addition to my portfolio, showcasing my abilities in handling and processing data effectively.
---
## 🔧 **Environment Setup**
This app has been built and tested in the following environment:
- **Operating System**: Ubuntu 22.04.5 LTS (Jammy)
- **Python Version**: Python 3.10.12
---
## 🤝 **Open Pull Requests**
If you find any bug, feel free to contact me by opening a pull request on GitHub or via email at **[email protected]**.
---
## ⚠️ **Disclaimer**
This app was developed for my portfolio and demonstration purposes only. The results are not guaranteed to be error-free and should not be used for critical decision-making.
