# Expert-Meeting-on-AI-and-TVET-2025
{{0-1}}
[qr-code](https://github.com/LiaPlayground/Expert-Meeting-on-AI-and-TVET-2025)
{{1}} What is LiaScript & what are the challenges in creating OERs?
{{2}} Short interactive tutorial...
{{3}} Building extensions
{{4}} Programming in Markdown
{{5}} Creating interactivity with AI
{{6}} Classrooms?
## LiaScript
{{1}}
#### Lack of technical skills
--{{1}}--
You can be an expert of Arts, Medicine, or History, but you might not be a developer. This is a significant issue, as most Open Educational Resources are created by teachers, professors, or researchers who may not be familiar with the technical aspects of digital content creation. If we are honest, the medium has evolved — from stone carvings and clay tablets to paper and writing, books and printing, and now computers and __PDFs__ — but the representation has remained largely the same. Despite the vast capabilities of computers, such as enabling speech, immersive 3D experiences, and interactive content, many OERs still do not fully leverage these possibilities.
{{2}}
#### Separation by Tools, Platforms, and Formats
--{{2}}--
There are numerous platforms, tools, and formats available for creating digital content. However, each platform creates its own isolated ecosystem with unique capabilities and limitations. Most of these solutions do not support multiple authors or versioning, which hinders collaborative content creation. Utilizing version control systems and platforms like GitHub or GitLab, which offer open review systems, discussion forums, wikis, and more, could address the majority of challenges we face in the creation of OER.
{{3}}
#### OER has _No Language & No Collaboration_
--{{3}}--
This brings us to the elephant in the room. In the open-source world, communities typically gather around programming languages, libraries, or frameworks. However, in the OER world, there is no equivalent creators mostly work on their own. Furthermore, most OER authoring tools offer a word processor-like environment, requiring users to memorize various point-and-click sequences. If there is no dedicated button, then a feature becomes inaccessible. This limitation significantly restricts the creativity and flexibility of content creators.
### History
!?[Industrial eLab Magdeburg](https://www.youtube.com/watch?v=bICfKRyKTwE)
### Hello World
--{{0}}--
!?[](media/liascript_0.webm)
Hello, my name is LiaScript, I am a Markdown-based language that has been specially developed to create educational materials.
The advantage of Markdown is that it is already widely used, easy to write and read, and supported by many platforms.
The biggest drawback, however, is that it is @burn(static as hell) and offers no interactivity.
{{1-2}}
--{{1}}--
!?[](media/liascript_1.webm)
So my creators set out to rethink Markdown from the ground up...
?[Giorgio Moroder](https://music.youtube.com/watch?v=zhl-Cs1-sG4&si=fwB6LT2I0rQ0_CGE&start=301&end=312&autoplay=1)
> ... Once you free your mind about a concept of Harmony and of music being "correct" you can do whatever you want ...
>
> -- Giorgio Moroder (inventor of disco music)
--{{2}}--
!?[](media/liascript_2.webm)
Actually, tables in Markdown are simple to create and, as mentioned, are quite @burn(static).
However, a table can also represent a dataset that strives for its ideal visualization.
{{2}}
| Animal | Weight in kg | Lifespan (years) | Mitogen |
| ----------------------- | -----------: | ---------------: | ------: |
| Mouse | 0.028 | 02 | 95 |
| Flying Squirrel | 0.085 | 15 | 50 |
| Brown Bat | 0.020 | 30 | 10 |
| Sheep | 90 | 12 | 95 |
| Human | 68 | 70 | 10 |
--{{3}}--
!?[](media/liascript_3.webm)
Another tabular structure can produce a different visualization that can be fine-tuned by the creator.
In total, I support 10 different types of visualizations.
{{3}}
| Seattle | Jan | Feb | Mar | Apr | May | Jun | Jul | Aug | Sep | Oct | Nov | Dec |
| -------:| ----:| ----:| ----:| ----:| ----:| ----:| ----:| ----:| ----:| ----:| ----:| ----:|
| 0 | 40.7 | 41.5 | 43.6 | 46.6 | 51.4 | 56.0 | 60.5 | 61.2 | 57.0 | 50.1 | 44.1 | 39.6 |
| 2 | 40.2 | 40.7 | 42.7 | 45.3 | 50.0 | 54.4 | 58.5 | 59.2 | 55.4 | 49.2 | 43.5 | 39.3 |
| 4 | 39.7 | 40.0 | 41.9 | 44.4 | 48.9 | 53.2 | 57.0 | 57.7 | 54.2 | 48.6 | 43.1 | 38.9 |
| 6 | 39.6 | 39.5 | 41.3 | 44.2 | 49.5 | 54.2 | 57.8 | 57.4 | 53.6 | 48.2 | 42.8 | 38.7 |
| 8 | 39.6 | 39.9 | 42.9 | 47.1 | 52.7 | 57.3 | 61.3 | 61.1 | 56.7 | 49.5 | 43.1 | 38.7 |
| 10 | 41.3 | 42.7 | 46.4 | 50.7 | 56.4 | 60.9 | 65.2 | 65.4 | 60.9 | 52.8 | 45.5 | 40.4 |
| 12 | 43.8 | 46.0 | 49.5 | 53.8 | 59.6 | 64.3 | 69.4 | 69.8 | 65.1 | 56.0 | 47.8 | 42.6 |
| 14 | 45.1 | 47.7 | 51.3 | 55.9 | 61.9 | 66.9 | 72.6 | 73.2 | 67.7 | 57.8 | 48.8 | 43.6 |
| 16 | 44.5 | 47.5 | 51.4 | 55.9 | 62.3 | 67.5 | 73.9 | 74.3 | 68.2 | 57.4 | 47.8 | 42.6 |
| 18 | 42.6 | 44.7 | 48.7 | 53.8 | 60.3 | 65.9 | 72.3 | 72.2 | 64.6 | 53.9 | 46.0 | 41.2 |
| 20 | 42.0 | 43.3 | 46.4 | 50.2 | 56.0 | 61.4 | 66.9 | 66.6 | 60.7 | 52.3 | 45.2 | 40.7 |
| 22 | 41.4 | 42.5 | 45.0 | 48.3 | 53.5 | 58.2 | 63.2 | 63.5 | 58.7 | 51.1 | 44.5 | 40.1 |
--{{4}}--
!?[](media/liascript_4.webm)
What Markdown has always lacked was the embedding of multimedia content ...
--{{5}}--
!?[](media/liascript_5.webm)
I support audio content ...
{{5-6}}
?[a horse](https://www.w3schools.com/html/horse.mp3 "hear a horse")
--{{6}}--
!?[](media/liascript_6.webm)
I can handle video as well, and of course, I work on feature phones even if they are offline.
{{6-7}}
!?[LiaScript on Nokia](https://www.youtube.com/watch?v=U_UW69w0uHE)
--{{7}}--
!?[](media/liascript_7.webm)
I can also try to embed other types of content that do not fall into either of the two categories
{{7}}
??[Esther’s scroll in a cover](https://sketchfab.com/3d-models/esthers-scroll-in-a-cover-21a13eba33cb4343bab56f0c0f982876 "Historical Museum of the City of Kraków")
--{{8}}--
!?[](media/liascript_8.webm)
And much, much more... We will soon show you how everything works.
{{8}}
```abc
X: 1
M: 4/4
L: 1/8
K: Emin
|:D2|"Em"EBBA B2 EB|~B2 AB dBAG|"D"FDAD BDAD|FDAD dAFD|
"Em"EBBA B2 EB|B2 AB defg|"D"afe^c dBAF|"Em"DEFD E2:|
```
@ABCJS.eval
--{{9}}--
!?[](media/liascript_9.webm)
You might have noticed that this document is being used like a PowerPoint presentation.
However, our intention was to utilize LiaScript in various contexts.
With LiaScript, you can create presentations, enable self-study through browser-based text-to-speech output, or read the content as a simple yet interactive textbook, without animations.
### Decentralized Sharing
--{{0}}--
You might be wondering what toolchain, compiler, or setup is required to create such documents. The answer is simple: none. Everything happens within the browser.
LiaScript is a Progressive Web App that can fetch content from various locations and through different protocols. The only requirement is a link to your document, which is attached as a URL parameter. You can share this link with your colleagues or clients, allowing them to directly access your content without the need for login, registration, or installation.
https://liascript.github.io/course/?https://raw.githubusercontent.com/LiaPlayground/Expert-Meeting-on-AI-and-TVET-2025/main/README.md
--{{1}}--
However, registering on GitHub or hosting content on your own server can be challenging for content creators. To address this, we have integrated various web technologies that enable sharing without the need for a server at all. You can easily use these technologies in your projects as well.
{{2}}
### Interplanetary File System (IPFS)
--{{2}}--
As a web developer, you should keep an eye on the Interplanetary File System (IPFS). IPFS is a protocol and network designed to create a content-addressable, peer-to-peer method of storing and sharing content in a distributed file system. It even enables the creation of distributed applications.
--{{3}}--
I won't go into further detail, but to our knowledge, IPFS is supported by browsers like Brave, Opera, and Aggregore.
{{3}}
* __ Brave: https://brave.com __
* __ Opera: https://www.opera.com __
* __ Agregore: https://agregore.mauve.moe __
{{4}}
- Hypercore: https://hypercore-protocol.org
- BitTorrent: https://en.wikipedia.org/wiki/BitTorrent
- Gemini: https://gemini.circumlunar.space
- IPFS: https://ipfs.tech
--{{4}}--
Aggregore is particularly noteworthy for its support of various protocols, including Hypercore, BitTorrent, and Gemini, next to IPFS.
{{5}}
### Onion-Share
--{{5}}--
If you are seeking a more secure and anonymously method to share your content, you might want to consider OnionShare. OnionShare is an open-source tool that allows you to securely and anonymously share files of any size. It works by starting a web server directly on your computer and making it accessible through an unguessable Tor web address. Thus LiaScript content can also be shared as an onion-URL via the Tor network.
https://onionshare.org
--{{6}}--
We have identified OnionShare as a valuable tool for delivering educational content to regions where internet access is restricted or monitored. This is particularly important in areas where education is prohibited for girls, women, minorities, or other marginalized groups. By using OnionShare, educators can bypass censorship and surveillance, providing crucial learning materials to those who need them most.
{{6}}
{{7}}
--{{7}}--
For more information checkout out the following resources:
HowTo at: https://liascript.github.io/blog/sharing-via-tor-and-onion-share/
!?[Sharing LiaScript via Tor](https://www.youtube.com/watch?v=-y7I3bIeB_I&start=621 "Tutorial on sharing LiaScript courses via the Tor-Network with OnionShare")
{{8}}
### WebTorrent
--{{8}}--
Last but not least, WebTorrent is a streaming torrent client for both web browsers and desktop applications. Written entirely in JavaScript, WebTorrent uses WebRTC for true peer-to-peer transport. No browser plugin, extension, or installation is required.
--{{9}}--
If you take a look at their documentation, it is quite straightforward. Within a few minutes, you can create an app that shares files via WebTorrent.
{{9}}
https://webtorrent.io/docs
--{{10}}--
You can try this out on [instant.io](https://instant.io); simply drag and drop a file and share the link or copy the magnet-URI to LiaScript. Once the content is loaded by LiaScript, every user also becomes a seeder of the content. This ensures that the content remains available even if the original creator is offline.
{{10}}
https://instant.io
## Tutorial
### One Document multiple Representations
--{{0}}--
Hi, I am a Markdown document that can be presented in
textbook mode, as slides, or as an interactive
presentation. Change the presentation mode an check out
what happens.
--{{1}}--
Any Markdown block can be prefixed with two braces that
contain a number to define when this block should appear in
the presentation.
{{1}}
* This list will be visible at step 1
* and will not be removed
--{{2}}--
In contrast the following table will only be visible at
step 2.
{{2-3}}
| Animal | weight in kg | Lifespan years |
|-----------------|-------------:|---------------:|
| Mouse | 0.028 | 02 |
| Sheep | 90 | 12 |
| Human | 68 | 70 |
--{{3}}--
As you might expect, I am a comment for animation step 3.
I will be visible in textbook mode or speak out loud in the
other modes. Try out to translate the document into another
language and checkout what happens.
{{3}}
``` markdown
--{{1}}--
Comments in LiaScript are prefixed with two braces that is
surrounded by two dashes. It shall contain some useful
information about the animation step.
```
{{3}}
> __To disable the google translation you have to reload this site.__
### Embeddings
??[falstad: Circuit Simulator](https://www.falstad.com/circuit/circuitjs.html?ctz=CQAgjCAMB0l3BWcMBMcUHYMGZIA4UA2ATmIxAUgpABZsKBTAWjDACgAncDQkPK7Hhp8qVMJDYBnEIOH9aNPCKjgQAMwCGAG0kM2Ad2695YHjIQoobAMYyh5y6d7YLtKLHhgkCaMWwkwPCwEDDwvFEsWUTYtOzkBexdLMRAmGDhiQhoETJRcDDBsGkgEYQkANwUlJKrlUVoqJHqYBE44h1qasTg2AHs3LJVi0hA0dxKVS2FsPpkQQaph4lHRWCQIS3oZ-qoFhpGYQhQmtdGzgTZBOYAxCFX4ODuPSHEIFhAAYQ0ABw1rAEsAC4aAB21j0V2EtxU6QgYFgbwgAEkQQATACu1mBYIhSio0JSr1SEAASgxJP9JNjwWwABaqaZsIA)
#### The Browser is the new OS
> “Any application that can be written in JavaScript, will eventually be written in JavaScript.”
>
> -- Atwood's Law
{{1}}
??[linux](https://bellard.org/jslinux/vm.html?url=alpine-x86.cfg&mem=192)
### Any Questions
## Extensions
http://algebrite.org/#API%20and%20scripting
https://cdn.jsdelivr.net/npm/[email protected]/dist/algebrite.bundle-for-browser.min.js
```
12 + 34
```
Algebrite.run(`@input`)
## Programming Extensions
[CSV](https://raw.githubusercontent.com/datasciencedojo/datasets/master/titanic.csv)
### Python with PyScript
> Source: https://github/LiaTemplates/PyScript
>
> `import: https://raw.githubusercontent.com/liaTemplates/PyScript/main/README.md`
``` python @PyScript.repl
import pyodide.http
import pandas as pd
from io import StringIO
async def fetch_data(url):
response = await pyodide.http.pyfetch(url)
csv_data = await response.string()
df = pd.read_csv(StringIO(csv_data))
return df
url = "https://raw.githubusercontent.com/datasciencedojo/datasets/master/titanic.csv"
Titanic = await fetch_data(url)
# Display the first few rows of the dataset
Titanic
```
---
```python @PyScript.repl
import matplotlib.pyplot as plt
# Calculate the absolute frequency of survivors and non-survivors
absolute_counts = Titanic.groupby(["Pclass", "Sex"])["Survived"].value_counts().unstack()
# Visualize the absolute frequencies
absolute_counts.plot(kind="bar", stacked=True, figsize=(10,6), edgecolor="black")
plt.title("Absolute frequency of survivors by passenger class and sex")
plt.xlabel("Passenger class and sex")
plt.ylabel("Number of passengers")
plt.xticks(rotation=0)
plt.legend(["Did not survive", "Survived"], title="Status")
plt.grid(axis="y", linestyle="--", alpha=0.7)
plt.show()
plt
```
### R - Women and Children First?
> Code Runner with lots of Programming languages: https://github.com/LiaScript/CodeRunner
>
> `import: https://raw.githubusercontent.com/LiaScript/CodeRunner/master/README.md`
``` r
library(ggplot2)
library(dplyr)
# Read CSV file
df <- read.csv("https://raw.githubusercontent.com/datasciencedojo/datasets/master/titanic.csv")
# Clean up Age (remove NA values)
df <- df %>% filter(!is.na(Age))
# Survival Rate based on sex and age (including men)
women_children_men <- df %>%
mutate(Category = case_when(
Sex == "female" & Age < 18 ~ "Female Child",
Sex == "female" & Age >= 18 ~ "Female Adult",
Sex == "male" & Age < 18 ~ "Male Child",
Sex == "male" & Age >= 18 ~ "Male Adult"
)) %>%
group_by(Category) %>%
summarise(SurvivalRate = mean(Survived), .groups = 'drop')
# Save the plot as a PNG file
png("women_children_men_survival.png", width = 800, height = 400)
ggplot(women_children_men, aes(x = Category, y = SurvivalRate, fill = Category)) +
geom_bar(stat = "identity", position = "dodge") +
ggtitle("Survival Rate of (women, men, and children) ") +
xlab("Category") +
ylab("Survival Rate") +
scale_fill_manual(values = c("blue", "red", "green", "purple"), name = "Category") +
theme_minimal()
dev.off()
```
@LIA.r
---
``` r
library(ggplot2)
library(dplyr)
# CSV-File
df <- read.csv("https://raw.githubusercontent.com/datasciencedojo/datasets/master/titanic.csv")
# Clean up Age (remove NA values)
df <- df %>% filter(!is.na(Age))
# PNG-File for the density plot
png("density_plot_survival.png", width = 800, height = 400)
ggplot(df, aes(x = Age, fill = as.factor(Survived))) +
geom_density(alpha = 0.5) +
# translate to english
ggtitle("Density Distribution of Age among Survivors and Non-Survivors") + +
xlab("Age") +
ylab("Density") +
scale_fill_manual(values = c("red", "blue"), name = "Survived", labels = c("No", "Yes")) +
theme_minimal()
dev.off()
```
@LIA.r
### More Examples
https://github.com/topics/liascript-template
### WebSerial & MicroPython
const video = document.querySelector("#videoElement")
if (video.srcObject === null) {
if (navigator.mediaDevices.getUserMedia) {
navigator.mediaDevices.getUserMedia({ video: true })
.then(function (stream) {
video.srcObject = stream
video.style.display = "block"
send.lia("Close Camera")
})
.catch(function (error) {
console.log("Something went wrong!")
send.lia("Camera Problem")
});
send.output("Waiting for Camera")
"LIA: wait"
} else {
"No Camera connected"
}
} else {
const tracks = video.srcObject.getTracks()
// Stop all tracks
tracks.forEach(track => track.stop())
video.style.display = "none"
video.srcObject = null
"Open Camera"
}
``` python
from arduino_alvik import ArduinoAlvik
from time import sleep_ms
# These two lines initialise the Arduino Alvik
alvik = ArduinoAlvik()
alvik.begin()
```
@WebSerial
``` python
# Make the two LEDs off initially
alvik.left_led.set_color(0, 0, 0)
alvik.right_led.set_color(0, 0, 0)
while True:
# Move forward
alvik.set_wheels_speed(50, 50) # Both motors forward at speed 50
alvik.left_led.set_color(1, 0, 0) # Red LED glows to indicate forward motion
alvik.right_led.set_color(1, 0, 0) # Red LED glows to indicate forward motion
sleep_ms(1000) # Move forward for 2 seconds
# Stop for 1 second
alvik.brake() # note this special function
alvik.left_led.set_color(0, 0, 0) # Turn off all the LEDs
alvik.right_led.set_color(0, 0, 0) # Turn off all the LEDs
sleep_ms(1000)
# Move backward
alvik.set_wheels_speed(-50, -50) # Both motors backward at speed -50
alvik.left_led.set_color(0, 1, 0) # Green LED glows to indicate backward motion
alvik.right_led.set_color(0, 1, 0) # Green LED glows to indicate backward motion
sleep_ms(1000) # Move backward for 1 seconds
# Stop for 1 second
alvik.brake()
alvik.left_led.set_color(0, 0, 0) # Turn off all the LEDs
alvik.right_led.set_color(0, 0, 0) # Turn off all the LEDs
sleep_ms(1000)
```
## JavaScript
### Interactive Diagrams
https://liascript.github.io/blog/creating-interactive-diagrams-with-chatgpt/
$a =$ @input,
$b =$ @input,
$c =$ @input
"LIASCRIPT: ### $$f(x) = x^{@input(`a`)} + x * @input(`b`) + @input(`c`)$$"
function func(x) {
return Math.pow(x, @input(`a`)) + @input(`b`) * x + @input(`c`);
}
function generateData() {
let data = [];
for (let i = -15; i <= 15; i += 0.01) {
data.push([i, func(i)]);
}
return data;
}
let option = {
grid: { top: 40, left: 50, right: 40, bottom: 50 },
xAxis: {
name: 'x',
minorTick: { show: true },
splitLine: { lineStyle: { color: '#999' } },
minorSplitLine: { show: true, lineStyle: { color: '#ddd' } }
},
yAxis: {
name: 'y', min: -10, max: 10,
minorTick: { show: true },
splitLine: { lineStyle: { color: '#999' } },
minorSplitLine: { show: true, lineStyle: { color: '#ddd' } }
},
series: [
{
type: 'line',
showSymbol: false,
data: generateData()
}
]
};
"HTML: <lia-chart option='" + JSON.stringify(option) + "'></lia-chart>"
### Interactive Geometry
> Source: https://github.com/LiaTemplates/GGBScript
>
> A GGBScript JavaScript interpreter based on JavaScript.
>
> `import: https://raw.githubusercontent.com/LiaTemplates/GGBScript/refs/heads/main/README.md`
``` js @GGBScript
Titel("Punkt A & B");
// Definiere einen Punkt
const A = Punkt(1, 2, "A");
const B = Punkt([4, 6], "B");
```
### Interactive Geometry 2
A = (
@input
,
@input
)
B = (
@input
,
@input
)
C = (
@input
,
@input
)
Rotation:
@input
°
``` js @GGBScript
UserAxisLimits(0,150,0,60);
const A = Punkt(@input(`A0`), @input(`A1`), "A");
const B = Punkt(@input(`B0`), @input(`B1`), "B");
const C = Punkt(@input(`C0`), @input(`C1`), "C");
const P = Polygon("A", "B", "C");
Farbe(P, "red");
const M = Mittelpunkt(P);
const P2 = Rotation(P, M, @input(`rotation`));
Farbe(P2, "blue");
Kreis(M, 16, "Kreis");
```
## Classrooms ?
