# #TWSThreeTierAppChallenge
## Overview
This repository hosts the `#TWSThreeTierAppChallenge` for the TWS community.
The challenge involves deploying a Three-Tier Web Application using ReactJS, NodeJS, and MongoDB, with deployment on AWS EKS. Participants are encouraged to deploy the application, add creative enhancements, and submit a Pull Request (PR). Merged PRs will earn exciting prizes!
**Get The Challenge here**
[](https://youtu.be/tvWQRTbMS1g?si=eki-boMemxr4PU7-)
## Prerequisites
- Basic knowledge of Docker, and AWS services.
- An AWS account with necessary permissions.
## Challenge Steps
- [Application Code](#application-code)
- [Jenkins Pipeline Code](#jenkins-pipeline-code)
- [Jenkins Server Terraform](#jenkins-server-terraform)
- [Kubernetes Manifests Files](#kubernetes-manifests-files)
- [Project Details](#project-details)
## Application Code
The `Application-Code` directory contains the source code for the Three-Tier Web Application. Dive into this directory to explore the frontend and backend implementations.
## Jenkins Pipeline Code
In the `Jenkins-Pipeline-Code` directory, you'll find Jenkins pipeline scripts. These scripts automate the CI/CD process, ensuring smooth integration and deployment of your application.
## Jenkins Server Terraform
Explore the `Jenkins-Server-TF` directory to find Terraform scripts for setting up the Jenkins Server on AWS. These scripts simplify the infrastructure provisioning process.
## Kubernetes Manifests Files
The `Kubernetes-Manifests-Files` directory holds Kubernetes manifests for deploying your application on AWS EKS. Understand and customize these files to suit your project needs.
## Project Details
🛠️ **Tools Explored:**
- Terraform & AWS CLI for AWS infrastructure
- Jenkins, Sonarqube, Terraform, Kubectl, and more for CI/CD setup
- Helm, Prometheus, and Grafana for Monitoring
- ArgoCD for GitOps practices
🚢 **High-Level Overview:**
- IAM User setup & Terraform magic on AWS
- Jenkins deployment with AWS integration
- EKS Cluster creation & Load Balancer configuration
- Private ECR repositories for secure image management
- Helm charts for efficient monitoring setup
- GitOps with ArgoCD - the cherry on top!
📈 **The journey covered everything from setting up tools to deploying a Three-Tier app, ensuring data persistence, and implementing CI/CD pipelines.**
## Getting Started
To get started with this project, refer to our [comprehensive guide](https://amanpathakdevops.medium.com/advanced-end-to-end-devsecops-kubernetes-three-tier-project-using-aws-eks-argocd-prometheus-fbbfdb956d1a) that walks you through IAM user setup, infrastructure provisioning, CI/CD pipeline configuration, EKS cluster creation, and more.
### Step 1: IAM Configuration
- Create a user `eks-admin` with `AdministratorAccess`.
- Generate Security Credentials: Access Key and Secret Access Key.
### Step 2: EC2 Setup
- Launch an Ubuntu instance in your favourite region (eg. region `us-west-2`).
- SSH into the instance from your local machine.
### Step 3: Install AWS CLI v2
``` shell
curl "https://awscli.amazonaws.com/awscli-exe-linux-x86_64.zip" -o "awscliv2.zip"
sudo apt install unzip
unzip awscliv2.zip
sudo ./aws/install -i /usr/local/aws-cli -b /usr/local/bin --update
aws configure
```
### Step 4: Install Docker
``` shell
sudo apt-get update
sudo apt install docker.io
docker ps
sudo chown $USER /var/run/docker.sock
```
### Step 5: Install kubectl
``` shell
curl -o kubectl https://amazon-eks.s3.us-west-2.amazonaws.com/1.19.6/2021-01-05/bin/linux/amd64/kubectl
chmod +x ./kubectl
sudo mv ./kubectl /usr/local/bin
kubectl version --short --client
```
### Step 6: Install eksctl
``` shell
curl --silent --location "https://github.com/weaveworks/eksctl/releases/latest/download/eksctl_$(uname -s)_amd64.tar.gz" | tar xz -C /tmp
sudo mv /tmp/eksctl /usr/local/bin
eksctl version
```
### Step 7: Setup EKS Cluster
``` shell
eksctl create cluster --name three-tier-cluster --region us-west-2 --node-type t2.medium --nodes-min 2 --nodes-max 2
aws eks update-kubeconfig --region us-west-2 --name three-tier-cluster
kubectl get nodes
```
### Step 8: Run Manifests
``` shell
kubectl create namespace workshop
kubectl apply -f .
kubectl delete -f .
```
### Step 9: Install AWS Load Balancer
``` shell
curl -O https://raw.githubusercontent.com/kubernetes-sigs/aws-load-balancer-controller/v2.5.4/docs/install/iam_policy.json
aws iam create-policy --policy-name AWSLoadBalancerControllerIAMPolicy --policy-document file://iam_policy.json
eksctl utils associate-iam-oidc-provider --region=us-west-2 --cluster=three-tier-cluster --approve
eksctl create iamserviceaccount --cluster=three-tier-cluster --namespace=kube-system --name=aws-load-balancer-controller --role-name AmazonEKSLoadBalancerControllerRole --attach-policy-arn=arn:aws:iam::626072240565:policy/AWSLoadBalancerControllerIAMPolicy --approve --region=us-west-2
```
### Step 10: Deploy AWS Load Balancer Controller
``` shell
sudo snap install helm --classic
helm repo add eks https://aws.github.io/eks-charts
helm repo update eks
helm install aws-load-balancer-controller eks/aws-load-balancer-controller -n kube-system --set clusterName=my-cluster --set serviceAccount.create=false --set serviceAccount.name=aws-load-balancer-controller
kubectl get deployment -n kube-system aws-load-balancer-controller
kubectl apply -f full_stack_lb.yaml
```
### Cleanup
- To delete the EKS cluster:
``` shell
eksctl delete cluster --name three-tier-cluster --region us-west-2
```
- To clean up rest of the stuff and not incure any cost
```
Stop or Terminate the EC2 instance created in step 2.
Delete the Load Balancer created in step 9 and 10.
Go to EC2 console, access security group section and delete security groups created in previous steps
```
## Contribution Guidelines
- Fork the repository and create your feature branch.
- Deploy the application, adding your creative enhancements.
- Ensure your code adheres to the project's style and contribution guidelines.
- Submit a Pull Request with a detailed description of your changes.
## Rewards
- Successful PR merges will be eligible for exciting prizes!
## Support
For any queries or issues, please open an issue in the repository.
---
Happy Learning! 🚀👨💻👩💻
