# Overview

Shell Script for automating time-lapse video creation from images, hosts on an Apache Web Server for easy viewing.

Another over a much shorter period in HD which was taken every 10 minutes.

[![SC2 Video](https://img.youtube.com/vi/qcc47tjRBUc/0.jpg)](https://www.youtube.com/embed/qcc47tjRBUc)

Here's an example time-lapse video I recorded of chilli peppers growing over a 7 month period (click to view on YouTube):

[![SC2 Video](https://img.youtube.com/vi/c2NePLQ2OQk/0.jpg)](https://www.youtube.com/embed/c2NePLQ2OQk)

There are other examples in my Timelapses playlist on YouTube.

# Prerequisites

## Enable Camera Module

First, make sure the camera interface is enabled, if you don't, you'll see the message `Camera is not enabled. Try running 'sudo raspi-config'`:

  1. Run `sudo raspi-config`

  2. Go to 'Interfacing Options'

  3. Select 'Camera'

  4. Select 'Yes' for enabling the camera

  5. Select 'Finish' in the main menu and then 'Yes' to reboot the Pi

## Install Apache

Update the package lists first ;

```bash

sudo apt update

sudo apt-get install apache2 -y

```

Adjust the Apache permissions to allow the pi user to write so the script does not need to run

as root and remove the default index.html so we see the pictures in the web root.

```bash

sudo usermod -a -G www-data pi

sudo chown -R -f www-data:www-data /var/www/html

sudo chmod g+w /var/www/html

sudo rm /var/www/html/index.html

```

## Imagemagick

Required to add timestamps to the jpg files

```bash

sudo apt-get install imagemagick

```

Check it installed by checking the version

```bash

convert --version

```

## ffmpeg

Install ffmpeg

```bash

sudo apt install -y ffmpeg

```

Check it installed by checking the version

```bash

ffmpeg -version

```

# Install piLapse

Install Pi-Lapse as Pi

```bash

cd ${HOME}

curl -LJO https://raw.githubusercontent.com/mrmebailey/pitimelapse/v1.1/timeLapse.sh

chmod 755 ./timeLapse.sh

```

Check it downloaded fine ;

```bash

./timeLapse.sh

```

You should see the output

```bash

This script will create a folder in the HTML Root with the project name and is intended to run from cron.

Usage: ./timeLapse.sh [Project-Name] [WIDTH] [HEIGHT] [QUALITY]

Example below...

./timeLapse.sh my_first_lapse 1024 768 30

```

# VNC Install Pi HD lens Only

Because the Pi runs headless we need to use VNC to logon to the Pi in order to focus the camera as no display is attached.

```bash

sudo apt update

sudo apt install realvnc-vnc-server realvnc-vnc-viewer

```

Now we need to enable VNC in raspi-config

```bash

sudo raspi-config

```

Navigate to Interfacing Options.

Scroll down and select VNC › Yes.

The final configuration item is to allow direct capture mode in VNC Viewer highlighted below, if this is not done then live capture will just hang.

![Alt Image text](/resources/direct_capture.png?raw=true "Direct Capture")

# Update Pi HDMI Settings for Live streaming over VNC

Edit the file /boot/config.txt and uncomment the line below otherwise you may experience the cannot display VNC Desktop error.

```

# uncomment if hdmi display is not detected and composite is being output

hdmi_force_hotplug=1

```

# Camera Focus Pi HD lens Only

Connect to the pi by downloading VNC Viewer and execute raspistill in live mode using the

command below.

```bash

raspistill -t -0

```

![Alt Image text](/resources/vnc_camera_command.png?raw=true "Camera Command")

Focus the camera on your subject in live view, do not forget to lock off the lens screws and to exit this you must use CNTL ^C from the terminal, ensure you do this before moving onto the next steps as only one process can access the camera at any one time.

![Alt Image text](/resources/vnc_focus.png?raw=true "Camera Command")

# First Time Lapse

Now we have the script we can start testing, execute this command which will create the first picture and the project directory in the web root for us.

```bash

./timeLapse.sh my_first_laspe  1024 768 30

```

If there was an issue with the camera or it is not connected properly you will get the error now, check the connections and that you have enabled the camera properly.

It is also worth noting that you will need to cancel the live view mode executed above as only one process can access the camera at any one time.  You can do this by hitting CNTL ^C.

```bash

ls -ltr /var/www/html/my_first_laspe/

```

```bash

total 244

-rw-r--r-- 1 pi pi 247283 Sep 30 11:12 1.jpg

```

Now when we run the script the second time it will create picture number 2 and build the videos with the data overlay.

```bash

./timeLapse.sh my_first_laspe  1024 768 30

ls -ltr /var/www/html/my_first_laspe/

```

The output will look like this.

```bash

total 592

-rw-r--r-- 1 pi pi 247283 Sep 30 11:12 1.jpg

-rw-r--r-- 1 pi pi 248216 Sep 30 11:12 2.jpg

-rw-r--r-- 1 pi pi  31630 Sep 30 11:13 timelapse.mp4

-rw-r--r-- 1 pi pi  33383 Sep 30 11:13 timelapse_banner.mp4

-rw-r--r-- 1 pi pi  33383 Sep 30 11:13 timelapse_banner_static.mp4

```

Now visit the pi with a browser and check your pictures and video all work...

```bash

http://

```

![Alt Image text](/resources/pi_first_proj.png?raw=true "Camera Command")

The final part is to define the crontab entry, now the settings here will depend on the quality you want which is not currently tuneable but essentially the smoother the timelapse the more pictures you need but depends on how quickly your target lapse environment changes.

So, for example to catch ice melting that out be each minute in a house as it will only last about 30 or 40 minutes.  The chilli peppers growing over months I found each hour was enough to show the plants growing.

Chill flowers came and went within 2-3 days but that required a medium of every 10 minutes but experiment.

In this example we will run every minute and show a melting lolly so let's get started....

Add the cron entry by executing the below command.

```bash

(crontab -l ; echo "* * * * * /home/pi/timeLapse.sh my_first_laspe  1024 768 30") | crontab

```

You can remove it or hash it out when you are done with this command

```bash

 ( crontab -l | grep -v -F "/home/pi/timeLapse.sh my_first_laspe  1024 768 30" ) | crontab -

```
