![encryption-c-rp2350](https://raw.githubusercontent.com/mytechnotalent/encryption-c-rp2350/main/encryption-c-rp2350.png)



## FREE Reverse Engineering Self-Study Course [HERE](https://github.com/mytechnotalent/encryption-c-rp2350)







# encryption-c-rp2350



`encryption-c-rp2350` is bare-metal Pico 2 firmware for hardened Ouroboros: 12-word lowercase passphrases, Argon2id/XChaCha20-Poly1305, and GPIO25/UART dispatch.



## Highlights



- RP2350 firmware build using the Pico SDK

- Strict 12-word lowercase passphrase policy

- Argon2id key derivation with generated artifact parameters

- XChaCha20-Poly1305 payload decryption

- GPIO25 LED control from payload byte `0`

- UART output from payload bytes `1..7`

- Host generator writes both JSON and generated firmware header



## Getting Started



Because `encryption-c-rp2350` is a bare-metal Pico SDK firmware project, you need the RP2350 toolchain installed on your system.



### 1. Install Toolchain Prerequisites



- Pico SDK 2.2.0+

- ARM GNU toolchain (`arm-none-eabi`)

- CMake and Ninja

- Python 3.x



**Linux:**



```bash

export PICO_SDK_PATH="$HOME/.pico-sdk/sdk/2.2.0"

```



**macOS:**



```bash

brew install cmake ninja arm-none-eabi-gcc python

export PICO_SDK_PATH="$HOME/.pico-sdk/sdk/2.2.0"

```



**Windows:**



Install PowerShell, Visual Studio Build Tools, CMake, Ninja, Python 3, and the ARM embedded toolchain. The provided build script configures the MSVC environment automatically.



### 2. Build the Firmware



```bash

mkdir -p build && cmake -S . -B build -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s && cmake --build build

```



Build-time artifact guardrail:



- The build regenerates `demo_artifact.h` from `scripts/demo_artifact.json` before compiling.

- The build fails if committed `include/demo_artifact.h` is stale relative to the JSON artifact.



Generated outputs:



- `build/encryption_app.elf`

- `build/encryption_app.uf2`



### 3. Flash the RP2350



**picotool:**



```bash

"$HOME/.pico-sdk/picotool/2.2.0-a4/picotool/picotool" load build/encryption_app.uf2 -f && "$HOME/.pico-sdk/picotool/2.2.0-a4/picotool/picotool" reboot

```



**BOOTSEL mode:**



```bash

cp build/encryption_app.uf2 /Volumes/RP2350/

```



### 4. Open the UART Demo



After flashing, connect a serial terminal at `115200` baud.



| Platform | Command |

| --- | --- |

| macOS | `screen /dev/tty.usbserial-* 115200` |

| Linux | `screen /dev/ttyACM0 115200` |

| Windows | PuTTY or another serial terminal |



The firmware prints a policy hint and then a `> ` prompt.



## Running the Demo



The RP2350 firmware enforces the same strict passphrase policy as the Rust hardened demo: Enter exactly 12 lowercase words under ASCII-whitespace normalization (spaces/tabs/newlines). Inputs like `hello`, empty lines, or non-policy strings are rejected with a policy hint.



Successful decrypt also requires that your input exactly matches the passphrase used to generate the current `scripts/demo_artifact.json` and `include/demo_artifact.h` pair.



If you generated the artifact with the default README command, enter this exact 12-word phrase:



```text

orbit olive ladder marble quartz canyon ripple saddle violet ember walnut falcon

```



On success:



- GPIO25 is driven high

- UART prints `hello` followed by CRLF



If the passphrase violates policy, the firmware prints:



```text

Enter exactly 12 lowercase words separated by spaces.

```



If your artifact was generated with a different passphrase, this phrase will return:



```text

Authentication failed.

```



Expected behavior summary:



```text

correct phrase for current artifact -> GPIO25 on + hello

wrong phrase for current artifact   -> Authentication failed.

```



## Hardened Construction



This firmware now implements the hardened Ouroboros construction:



- Argon2id key derivation

- 16-byte random salt

- 24-byte XChaCha20 nonce

- XChaCha20-Poly1305 authenticated decryption

- fixed 48-byte payload dispatch



The JSON artifact schema matches the Rust repo:



- `format`

- `memory_kib`

- `iterations`

- `parallelism`

- `salt_hex`

- `nonce_hex`

- `ciphertext_and_tag_hex`



Important: the RP2350 cannot run the Rust repo's 1 GiB desktop demo profile in SRAM. This repo uses the same algorithm and artifact shape, but the checked-in embedded profile is calibrated for the microcontroller:



- `memory_kib: 64`

- `iterations: 3`

- `parallelism: 1`



That is an implementation constraint of the hardware, not a change in the cryptographic construction.



## Generating Hardened Demo Artifacts



The `scripts/dec.py` script is hardened-only and writes both:



- `scripts/demo_artifact.json`

- `include/demo_artifact.h`



Why those byte arrays are compiled into firmware:



- RP2350 firmware has no runtime JSON parser/filesystem in this demo path.

- `include/demo_artifact.h` is generated from the JSON artifact so the exact salt, nonce, and ciphertext/tag bytes are embedded in flash.

- This is provisioned data, not hand-written cryptographic constants; regenerate with `scripts/dec.py` whenever rotating passphrase or payload.



Run it with a strict 12-word lowercase passphrase:



```bash

python3 scripts/dec.py --key "orbit olive ladder marble quartz canyon ripple saddle violet ember walnut falcon" --text "hello"

```



By default this updates the embedded JSON artifact and the generated firmware header directly (no manual copy/paste needed).



To sync the committed header from an existing JSON artifact without re-encrypting:



```bash

python3 scripts/dec.py --from-json scripts/demo_artifact.json --header-out include/demo_artifact.h

```



`dec.py` enforces the same passphrase policy as the firmware: exactly 12 lowercase words under ASCII-whitespace normalization.



If your local `.venv` has native-extension architecture mismatch errors (for example, `_cffi_backend` incompatible architecture), rebuild it first:



```bash

rm -rf .venv

python3 -m venv .venv

source .venv/bin/activate

python3 -m pip install -U pip setuptools wheel

python3 -m pip install argon2-cffi pynacl

```



Otherwise, install required Python packages first:



```bash

python3 -m pip install argon2-cffi pynacl

```



You can override the output paths if needed:



```bash

python3 scripts/dec.py --key "<12 lowercase words>" --text "hello" --out scripts/demo_artifact.json --header-out include/demo_artifact.h

```



Then rebuild and flash:



```bash

cmake -S . -B build -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s

cmake --build build

```



Payload layout is fixed:



- byte `0`: LED state (`1` on, `0` off)

- bytes `1..7`: UART output bytes



By default, `dec.py` appends CRLF (`\r\n`) to `--text`, so output must fit within 7 bytes after that append. Use `--no-crlf` to keep the full 7-byte capacity for raw text.



## Security Notes



The firmware does not contain a plaintext secret and does not bypass the entered phrase. To light GPIO25 and print the payload, an attacker still needs a passphrase that derives the correct key for the embedded artifact.



Implementation-accurate claim boundary:



- This demo enforces cryptographic gating in the intended firmware path (policy check + Argon2id + authenticated decryption before payload dispatch).

- This demo does not claim full side-channel resistance or fault-injection resistance.

- Branchless code alone is not sufficient to claim side-channel or fault resistance.



Scope boundary: claims here are limited to intended execution with unmodified firmware; firmware patching, instruction-level control, and active fault injection are out of scope.



The important variables are:



- passphrase entropy

- Argon2id work factor

- physical extraction and side-channel assumptions for the device



### Side-Channel and Fault Hardening Checklist



Use this checklist before making stronger claims than "cryptographically gated demo path":



- Enable secure boot / signed image verification so patched firmware cannot run.

- Lock debug/programming interfaces in production lifecycle states.

- Add voltage/clock/temperature glitch detection and safe-fail behavior.

- Use constant-time verification paths where applicable and avoid secret-dependent early exits.

- Add redundant checks or control-flow integrity for critical auth decisions.

- Minimize secret lifetime in RAM and verify compiler-retained zeroization.

- Perform hardware side-channel and fault-injection testing on target boards.

- Get third-party security review before claiming resistance properties.



### Quantum Threat Model



Short answer: **not in the strict post-quantum-cryptography (PQC) sense**.



- This framework does not implement a NIST PQC KEM or signature scheme.

- Security here is symmetric-key plus password-guessing cost.

- Against Grover-style brute force, symmetric search exponents are roughly halved.



So the right claim is: **high modeled brute-force cost under stated entropy and KDF assumptions**, not "quantum-proof."



### Crack-Time Math (Reference Row)



The hardened framework uses the same reference entropy row and the same classical versus optimistic Grover-style formulas as the Rust repo:



```text

T_avg_classical_years = 2^(H-1) / (r * 31,557,600)

T_avg_quantum_years   = 2^(H/2 - 1) / (r_q * 31,557,600)

```



For the 12-word Diceware policy reference row:



- `H ≈ 155.1`

- `r = 0.1/s`

- `r_q = 0.1/s`

- Classical: `~7.76e39 years`

- Quantum (optimistic Grover model): `~3.51e16 years`



Age-of-universe comparison (`≈ 1.38e10 years`):



- Classical ratio: `~5.6e29`

- Quantum ratio: `~2.5e6`



Important: those are the same paper-standard reference numbers used in the Rust repo. They are not a measured claim that the RP2350's checked-in `memory_kib: 64` profile has the same real-world per-guess cost as the Rust repo's 1 GiB desktop demo profile.



#### Reproducibility Snippet



```python

SECONDS_PER_YEAR = 365.25 * 24 * 3600



def avg_years_classical(H, r):

	return 2 ** (H - 1) / (r * SECONDS_PER_YEAR)



def avg_years_quantum(H, r_q):

	return 2 ** (H / 2 - 1) / (r_q * SECONDS_PER_YEAR)



print(avg_years_classical(155.1, 0.1))

print(avg_years_quantum(155.1, 0.1))

```



This project is a demonstrator firmware, not a third-party audited security product or formal security proof.



## Project Layout



- `src/main.c`: firmware entry point

- `src/cli.c`: UART prompt and passphrase handling

- `src/auth.c`: Argon2id + XChaCha20-Poly1305 authentication path

- `src/mbedtls_shims.c`: minimal zeroize shim for the AEAD subset

- `include/auth.h`: public auth API and constants

- `include/demo_artifact.h`: generated artifact header consumed by firmware

- `scripts/dec.py`: hardened artifact generator

- `scripts/demo_artifact.json`: JSON source-of-truth artifact

- `paper.typ`: hardened paper







## License



MIT — see [LICENSE](LICENSE).
