# Java API for Thing Descriptions of WoT (JDTs)
[](https://github.com/oeg-upm/wot-jtd/releases)] [](https://search.maven.org/search?q=g:%22es.upm.fi.oeg%22%20AND%20a:%22wot-jtd%22) [](https://opensource.org/licenses/Apache-2.0) [](https://github.com/oeg-upm/wot-jtd/stargazers)
The JDT is an ORM implementation of the current [Thing Description](https://www.w3.org/TR/wot-thing-description/) model standardised by the [W3C Web of Things group](https://www.w3.org/WoT/). The current features are:
* Serialise:
* Serialise any Thing Description as a Java Object, i.e., a JDT
* Serialise a JDT from a JSON-LD framed document
* Serialise a JDT from a set of RDF triples
* Round trip-translation:
* Translate from a JSON-LD framed document into a set of equivalent RDF triples
* Translate a set of RDF triples into its equivalent JSON-LD framed document
* Validation
* Validate a JTD using [SHACL shapes](https://www.w3.org/TR/shacl/)
* Validate a JTD using [JSON schema](https://json-schema.org/) **(coming soon)**
* Validate a JTD according to the [restrictions specified in the standard](https://www.w3.org/TR/wot-thing-description/) **(coming soon)**
If you have any feedback or feature suggestion, please let us know posting an issue with the label **feedback**
## Table of contents
* Installation
* Model
* Usage:
* Serialisation of JTDs:
* From JSON-LD framed document
* From RDF triples
* Deserialisation of JTDs:
* To JSON-LD framed
* To RDF triples
* JDT validation:
* Using SHACL shapes
* Using JSON schema (**coming soon**)
* Using restrictions in the model (**coming soon**)
## Installation:
Import the JDTs library as a maven dependency, **be sure to specify the latest version**:
```
es.upm.fi.oeg
wot-jtd
0.2.2
```
Alternatively, the dependency can be installed manually. First, download the latest jar from the [releases section](), and then install the dependency as follows (**be sure to specify the latest version**):
````
mvn install:install-file -Dfile=wot-jtd.jar -DgroupId=es.upm.fi.oeg -DartifactId=wot-jtd -Dversion=0.2.2 -Dpackaging=jar
````
Check our [Maven Central Repository page](https://search.maven.org/artifact/es.upm.fi.oeg/wot-jtd/0.2.2/jar) to discover other installation options like Gradle Groovy or Kotlin, Scala, and others.
## Model
The JDT library implement as Java objects the whole model, and its restrictions, defined in the [Thing Description standard](https://www.w3.org/TR/wot-thing-description/). The overview of the model is the following:
## Usage
### Serialisation of JTDs:
For the next examples, let's assume the following java variables containing the same Thing description:
````
String strJsonTD = "{ \"@context\": \"https://www.w3.org/2019/wot/td/v1\",\n" +
" \"id\": \"urn:dev:ops:32473-WoTLamp-1234\",\n" +
" \"title\": \"MyLampThing\",\n" +
" \"securityDefinitions\": { \"nosec_sc\": { \"scheme\": \"nosec\" }},\n" +
" \"security\": \"nosec_sc\",\n" +
" \"properties\": {\n" +
" \"status\": {\n" +
" \"type\": \"string\",\n" +
" \"forms\": [{\"href\": \"https://mylamp.example.com/status\"}]\n" +
" }\n" +
" }\n" +
"}";
````
````
Model modelTD = ModelFactory.createDefaultModel();
String strRdfTD = "@prefix dc: .\n" +
"@prefix td: .\n" +
"@prefix jsonschema: .\n" +
"@prefix hctl: .\n" +
"\n" +
"\n" +
" dc:title \"MyLampThing\" ;\n" +
" td:hasPropertyAffordance [\n" +
" a ;\n" +
" jsonschema:propertyName \"status\" ;\n" +
" td:hasForm [ hctl:hasTarget ]\n" +
" ] ;\n" +
" td:hasSecurityConfiguration ;\n" +
" td:securityDefinitions [ td:scheme \"nosec\" ] .";
##### Read the string variable into the jena model
modelTD.read(new ByteArrayInputStream(strRdfTD.getBytes()), null, "Turtle");
````
The following serialisation operations consists of building a JTD object Thing from either a JSON-LD framed representation or a set of RDF triples.
##### From JSON-LD framed document
````
JsonObject jsonTD = JTD.parseJson(strJsonTD);
Thing thing = Thing.fromJson(jsonTD);
thing = (Thing) JTD.instantiateFromJson(jsonTD, Thing.class); # Alternativelly
````
Notice that using the method `JTD.instantiateFromJson(jsonTD, Thing.class)` any other class from the model can be serialised.
##### From RDF triples
In order to build a JTD object from a set of RDF triples there are two main methods:
##### A) Build a list of JTDs in case that the triples contain more than one Thing resource.
`````
List things = fromRDF(modelTD)
`````
##### B) Build a unique JTDs providing the RDF resource URI.
`````
Thing thing = fromRDF(modelTD, "urn:dev:ops:32473-WoTLamp-1234")
`````
### Deserialisation of JTDs:
##### To JSON-LD framed
````
JsonObject jsonTD = thing.toJson()
jsonTD = JTD.toJson(thing) # Alternativelly
````
Notice that using the method `JTD.toJson(thing)` any other class from the model can be deserialised.
##### To RDF triples
````
Model modelTD = JTD.toRDF(thing)
# Alternativelly
JsonObject jsonTD = thing.toJson()
modelTD = JTD.toRDF(jsonTD)
````
Notice that using the method alternative `JTD.toRDF(jsonTD)` there is actually no need to serialise the JSON-LD framed `jsonTD` as a Java object, it can be directly translated into RDF.
### JDT validation
##### Using SHACL shapes
Currently, the Web of Things provides [an official SHACL shape document](https://github.com/w3c/wot-thing-description/blob/main/validation/td-validation.ttl) for validating Thing Descriptions. This shape, or any other, can be used to validate a JTD Thing as follows:
````
String shapesURI = "https://raw.githubusercontent.com/w3c/wot-thing-description/main/validation/td-validation.ttl"
Model shapesGraph = RDFDataMgr.loadModel(shapesURI, Lang.TURTLE);
ValidationReport shapeReport = JTD.validateWithShape(thing, shapesGraph);
````
##### Using JSON schema (*comming soon*)
##### Using restrictions in the model (*comming soon*)
### Support or Contact
WoT-JTD was created by [Andrea Cimmino](https://scholar.google.es/citations?user=_6U9WMcAAAAJ&hl=es&oi=ao) ([email protected]) and [Raúl García Castro](http://garcia-castro.com/) ([email protected]) at the [Universidad Politécnica de Madrid](https://www.upm.es/) in the research group [Ontology Engineering Group](https://oeg.fi.upm.es/).
