# CCNA2020_StaticRouting
靜態路由
是一種路由方式，由網路管理員手動操作路由表，將路由項 routing entry 輸入至路由表中。
# 架構圖範例
IP 的位址與子遮罩都攸關流量控制（分流）。
Internet （WAN）
|
|
|
(LAN)
|
|
|
Router 1 ----------- SW ---------- workstations
192.168.1.254 (private ip)
NAT (public ip)
|
|
|
(Protected LAN)
|
|
|
Router 2
192.168.1.100 (public ip)
192.168.1.254 (default gW)
192.168.100.1 (private ip)
|
|
|
SW
|
|
|
Group of Workstations
| | |
My PC(admin) Mail Server Web Server
192.168.100.24 192.168.100.3 192.168.100.4
192.168.100.1 (default GW)
# 發送回應和接收請求
receive request
Web Server <----------- Router 2 <----------- Router 1 <----------- Internet
192.168.100.4 192.168.100.1 192.168.1.254
192.168.100.1 192.168.1.254 NAT
send response
Web Server -----------> Router 2 -----------> Router 1 -----------> Internet
192.168.100.4 192.168.100.1 192.168.1.254
192.168.100.1 192.168.1.254 NAT
# 靜態路由的設定
My PC (admin)
IP: 192.168.100.24
netmask: 255.255.255.0
gateway: 192.168.100.1
hostname: clientlinux.centos.PkateQ
DNS: 168.95.1.1 (等待確認)
Router 2 (受保護內網的路由器)
>
兩張 NIC
eth0: 192.168.1.100/24 (public ip)
eth1: 192.168.100.1/24 (private ip)
Router 1 (連接外網與內網的路由器)
>
兩張 NIC
對外的網卡 > 設定在 eth1 介面
而對內部的 > 設定在 eth0 介面 > 192.168.1.254
# 實際 CMD
再次感謝造福系統與網路後輩芸芸眾生的鳥哥！
http://linux.vbird.org/linux_server/0230router.php#route_static
