# Overview
A Swift Package that makes SwiftUI shapes easier to make by redefining them as an array of styled corners. (The logo above was created in 100 lines + SwiftUI Text)
Features:
- [`Corner`](#corner), a `CGPoint` with `style`.
- [`CornerStyle`](#cornerstyle) options: `.point`, `.rounded`, `.straight`, `.cutout`, and `.concave`
- Basic shapes like [`CornerRectangle`](#basic-shapes), [`CornerTriangle`](#basic-shapes), and [`CornerPentagon`](#basic-shapes) with stylable corners.
- [`CornerShape`](#cornershape), a protocol for making your own open or closed shapes out of an array of Corners.
- [`CornerCustom`](#cornercustom), for building corner shapes inline without making a new type.
- Add a [`Notch`](#notch) of any `NotchStyle` inbetween two corners.
- [`.addOpenCornerShape()`](#add-cornershape) or [`.addClosedCornerShape()`](#add-cornershape) for adding a few corners to a SwiftUI `Path`
- [`Vector2`](#vector2), a new type similar to `CGPoint` but used to do vector math.
- [`Vector2Representable`](#vector2representable) protocol that adds a `.vector` property needed to conform to other Vector2-related protocols.
- [`Vector2Algebraic`](#vector2algebraic) protocol used to add vector algebra capabilities to `Vector2`
- [`Vector2Transformable`](#vector2transformable) protocol with methods for transforming arrays of points.
- [`RectAnchor`](#rectanchor), an enum for all major anchor points on a rectangle. Used for transform functions.
- [`RelatableValue`](#relatablevalue), an enum used to store `.relative` or `.absolute` values.
- [`SketchyLine`](#sketchyline), an animatable line `Shape` that aligns to frame edges and can extend beyond the frame.
- [`.emboss()` or `.deboss()`](#emboss-or-deboss) any SwiftUI `Shape` or `View`.
- [`AnimatablePack`](#animatablepack) as an alternative to `AnimatablePair` that takes any number of properties.
# Demo App
The `Example` folder has an app that demonstrates the features of this package.
# Installation and Usage
This package is compatible with iOS 14+, macOS 11+, watchOS 7+, tvOS 14+, and visionOS.
1. In Xcode go to `File -> Add Packages`
2. Paste in the repo's url: `https://github.com/ryanlintott/ShapeUp` and select by version.
3. Import the package using `import ShapeUp`
# Is this Production-Ready?
Really it's up to you. I currently use this package in my own [Old English Wordhord app](https://oldenglishwordhord.com/app).
Additionally, if you find a bug or want a new feature add an issue and I will get back to you about it.
# Support This Project
ShapeUp is open source and free but if you like using it, please consider supporting my work.
[](https://ko-fi.com/X7X04PU6T)
Or you can buy a t-shirt with the ShapeUp logo
- - -
# Features
## Corner
A point with a specified `CornerStyle` used to draw paths and create shapes.
```swift
Corner(.rounded(radius: 5), x: 0, y: 10)
```
Corners store no information about their orientation or where the previous and next points are located. When they're put into an array their order is assumed to be their drawing order. This means you can generate a `Path` from this array. By default this path is assumed to be closed with the last point connecting back to the first.
```swift
[
Corner(.rounded(radius: 10), x: 0, y: 0),
Corner(.cutout(radius: 5), x: 10, y: 0),
Corner(.straight(radius: 5), x: 5, y: 10)
].path()
```
## CornerStyle
An enum storing style information for a `Corner`. In all cases, the radius is a [`RelatableValue`](#relatablevalue) that can either be an absolue value or relative to the length of the shortest line from that corner.
`.point`
A simple point corner with no properties.
`.rounded(radius: RelatableValue)`
A rounded corner with a radius.
`.concave(radius: RelatableValue, radiusOffset: CGFloat)`
A concave corner where the radius determines the start and end points of the cut and the radius offeset is the difference between the concave radius and the radius. The radiusOffset is mainly used when insetting a concave corner and is often left with the default value of zero.
`.straight(radius: RelatableValue, cornerStyles: [CornerStyle] = [])`
A straight chamfer corner where the radius determines the start and end points of the cut. Additional cornerstyles can be used on the two resulting corners of the chamfer. (You can continue nesting recursively.)
`.cutout(radius: RelatableValue, cornerStyles: [CornerStyle] = [])`
A cutout corner where the radius determines the start and end points of the cut. Additional cornerstyles can be used on the three resulting corners of the cut. (Again, you can continue nesting recursively.)
## Basic Shapes
`CornerRectangle`, `CornerTriangle`, and `CornerPentagon` are pre-built shapes where you can customize the style of any corner.
Examples:
```swift
CornerRectangle([
.topLeft: .straight(radius: 60),
.topRight: .cutout(radius: .relative(0.2)),
.bottomRight: .rounded(radius: .relative(0.8)),
.bottomLeft: .concave(radius: .relative(0.2))
])
.fill()
CornerTriangle(
topPoint: .relative(0.6),
styles: [
.top: .straight(radius: 10),
.bottomRight: .rounded(radius: .relative(0.3)),
.bottomLeft: .concave(radius: .relative(0.2))
]
)
.stroke()
CornerPentagon(
pointHeight: .relative(0.3),
topTaper: .relative(0.1),
bottomTaper: .relative(0.3),
styles: [
.topRight: .concave(radius: 30),
.bottomLeft: .straight(radius: .relative(0.3))
]
)
.fill()
```
## CornerShape
A protocol for creating shapes built from an array of `Corner`s. The path and inset functions needed to conform to SwiftUI InsettableShape are already implemented.
### How to build a CornerShape
- Set insetAbount zero (this property is used if the shape inset).
- Set the closed property to define if your shape should be closed or left open.
- Write a function that returns an array of corners.
```swift
public struct MyShape: CornerShape {
public var insetAmount: CGFloat = .zero
public let closed = true
public func corners(in rect: CGRect) -> [Corner] {
[
Corner(x: rect.midX, y: rect.minY),
Corner(.rounded(radius: 5), x: rect.maxX, y: rect.maxY),
Corner(.rounded(radius: 5), x: rect.minX, y: rect.maxY)
]
}
}
```
### Using A CornerShape
A `CornerShape` can be used in SwiftUI Views the same way as `RoundedRectangle` or similar.
```swift
MyShape()
.fill()
```
The corners can also be accessed directly for use in a more complex shape
```swift
public func corners(in rect: CGRect) -> [Corner] {
MyShape()
.corners(in: rect)
.inset(by: 10)
.addingNotch(Notch(.rectangle, depth: 5), afterCornerIndex: 0)
}
```
## CornerCustom
Sometimes you might want to make a shape inline without defining a new struct. `CornerCustom` is a `CornerShape` that takes a closure that returns an array of `Corner`s. The closure itself needs to be `Sendable` so that it can be used to generate a path for a SwiftUI `Shape`.
```swift
CornerCustom { rect in
[
Corner(x: rect.midX, y: rect.minY),
Corner(.rounded(radius: 10), x: rect.maxX, y: rect.maxY),
Corner(.rounded(radius: 10), x: rect.minX, y: rect.maxY)
]
}
.strokeBorder(lineWidth: 5)
```
## Notch
Sometimes you want to cut a notch in the side of a shape. This can be tricky to do when the line is at an odd angle but `Notch` makes it easy. A `Notch` has a `NotchStyle`, position, length and depth.
The following code adds a rectangular notch between the second and third corner. The `addingNotch()` function makes all the necessary calculations to add the corners representing that notch into the `Corner` array.
```swift
let notch = Notch(.rectangle, position: .relative(0.5), length: .relative(0.2), depth: .relative(0.1))
let corners = corners.addingNotch(notch, afterCornerIndex: 1)
```
### NotchStyle
Two basic styles are `.triangle` and `.rectangle` and both allow customization of the corner styles for the 2 or 3 resulting notch corners.
```swift
/// Specify styles for each corner
let notch1 = .triangle(cornerStyles: [.rounded(radius: 10), .point, .straight(radius: 5)])
/// Or specify one style for all
let notch2 = .rectangle(cornerStyle: .rounded(radius: .relative(0.2))
```
There is also a `.custom` notch style that takes a closure that returns an array of `Corner`s based on a `CGRect` that matches the size and orientation of the notch.
```swift
let notch = .custom { rect in
[
Corner(x: rect.minX, y: rect.minY),
Corner(x: rect.minX, y: rect.midY),
Corner(.rounded(radius: 15), x: rect.midX, y: rect.maxY),
Corner(x: rect.maxX, y: rect.midY),
Corner(x: rect.maxX, y: rect.minY)
]
}
```
## Add CornerShape
Shapes made completely with corners have their limitations. Only straight lines and arcs are possible. If you want to use corners to draw only a portion of your shape you can do that too with `.addOpenCornerShape()` and `.addClosedCornerShape()` functions added to `Path`
## Vector2
A vector type used as an alternative to CGPoint that conforms to all the Vector2 protocols.
## Vector2Representable
A protocol that adds the `vector: Vector2` property. `Vector2`, `CGPoint`, and `Corner` all conform to this and it's required for any other Vector2 protocols.
Other properties and methods:
```swift
point: CGPoint
corner(_ style:) -> Corner
```
Array extensions:
```swift
points: [CGPoint]
vectors: [Vector2]
corners(_ style: CornerStyle?) -> [Corner]
corners(_ styles: [CornerStyle?]) -> [Corner]
bounds: CGRect
center: CGPoint
anchorPoint(_ anchor: RectAnchor) -> CGPoint
angles: [Angle]
```
## Vector2Algebraic
A protocol that adds vector math. Only applied to `Vector2` by default but can be added to any other `Vector2Representable` if need be.
Functions include: magnitude, direction, normalized, addition, subtraction, and multiplication or division with scalars.
## Vector2Transformable
A protocol that adds transformation functions (move, rotate, flip, inset) to any `Vector2Representable` or array of that type. Applied to `Vector2`, `CGPoint`, and `Corner`.
## RectAnchor
An enum to indicate one of 9 anchor locations on a rectangle. It's primarily used to quickly get `CGPoint` values from `CGRect`
```swift
// Current method
let point = CGPoint(x: rect.minX, y: rect.minY)
// ShapeUp method
let point = rect.point(.topLeft)
```
This is especially helpful when getting an array of points
```swift
// Current method
let points = [
CGPoint(x: rect.minX, y: rect.midY),
CGPoint(x: rect.midX, y: rect.midY),
CGPoint(x: rect.maxX, y: rect.maxY)
]
// ShapeUp method
let points = rect.points(.left, .center, .bottomRight)
```
## RelatableValue
A handy enum that represents either a relative or absolute value. This is used in lots of situations throughout ShapeUp to give flexibility when defining parameters.
When setting a corner radius you might want a fixed value like 20 or you might want a value that's 20% of the maximum so that it will scale proportionally. `RelatableValue` gives you both of those options.
```swift
let absolute = RelatableValue.absolute(20)
let relative = RelatableValue.relative(0.2)
```
Later, the value is determined by running the `value(using total:)` function. Absolute values will always be the same but any relative values will be calculated. In the case of a corner radius, the total would be the maximum radius that would fit that corner given the length of the two lines and the angle of the corner.
```swift
let radius = relatableRadius.value(using: maxRadius)
```
For ease of use, `RelatableValue` conforms to `ExpressibleByIntegerLiteral` and `ExpressibleByFloatLiteral`. This means in many cases you can omit `.absolute()` when writing absolute values.
```swift
// Both are the same
let cornerStyle = .rounded(radius: .absolute(5))
let cornerStyle = .rounded(radius: 5)
```
## SketchyLine
A animatable line Shape with ends that can extend and a position that can offset perpendicular to its direction.
```swift
Text("Hello World")
.alignmentGuide(.bottom) { d in
// moves bottom alignment to text baseline
return d[.firstTextBaseline]
}
.background(
SketchyLines(lines: [
.leading(startExtension: -2, endExtension: 10),
.bottom(startExtension: 5, endExtension: 5, offset: .relative(0.05))
], drawAmount: 1)
.stroke(Color.red)
, alignment: .bottom
)
```
## Emboss or Deboss
Extensions for `InsettableShape` and `View` that create an embossed or debossed effect.
## AnimatablePack
*\*Xcode 16+, iOS 17+, macOS 14+, watchOS 10+, tvOS 17+*
Animate lots of properties in a `Shape` using `AnimatablePack` instead of nesting `AnimatablePair` types
Here is an example of animatableData using AnimatablePair:
```swift
struct MyShape: Animatable {
var animatableData: AnimatablePair> {
get { AnimatablePair(insetAmount, AnimatablePair(cornerRadius, rotation)) }
set {
insetAmount = newValue.first
cornerRadius = newValue.second.first
rotation = newValue.second.second
}
}
}
```
You can see how it would get quite large once you start adding more than a few properties.
Here's how to use AnimatablePack instead:
```swift
struct MyShape: Animatable {
var animatableData: AnimatablePack {
get { AnimatablePack(insetAmount, cornerRadius, rotation) }
set { (insetAmount, cornerRadius, rotation) = newValue() }
}
}
```
