**INSERT**, **UPDATE**, and **DELETE** operations in the database involve the retrieval of changing and existing values. On the database side, these changes are recorded using **CDC** (Change Data Capture).
For **CDC** in MSSQL, it's worth noting the following:
- Prior to **SQL Server 2016 SP1**, it is supported in the Developer Edition and Enterprise Edition.
- After **SQL Server 2016 SP1**, it is also supported in the Standard Edition.
Additionally, we can track and record this data using triggers, but it will incur extra costs. CDC, on the other hand, can provide the service by reading the desired information from the database logs when activated.
As mentioned below, we will track changes made in the table under the specified schema. However, if desired, we can also track a specific column under this table.
Now, let's set up a sample project using Docker.
**docker-compose.yml**
```yml
version: '3.1'
services:
zookeeper:
image: wurstmeister/zookeeper:latest
environment:
ZOOKEEPER_CLIENT_PORT: 2181
ZOOKEEPER_TICK_TIME: 2000
ports:
- 2181:2181
- 2888:2888
- 3888:3888
kafka1:
image: wurstmeister/kafka:latest
restart: "no"
ports:
- 9092:9092
environment:
KAFKA_BROKER_ID: 1
KAFKA_ZOOKEEPER_CONNECT: zookeeper:2181
KAFKA_LISTENERS: INTERNAL://:29092,EXTERNAL://:9092
KAFKA_ADVERTISED_LISTENERS: INTERNAL://kafka1:29092,EXTERNAL://localhost:9092
KAFKA_LISTENER_SECURITY_PROTOCOL_MAP: INTERNAL:PLAINTEXT,EXTERNAL:PLAINTEXT
KAFKA_INTER_BROKER_LISTENER_NAME: INTERNAL
KAFKA_OFFSETS_TOPIC_REPLICATION_FACTOR: 1
kafka2:
image: wurstmeister/kafka:latest
restart: "no"
depends_on:
- kafka1
ports:
- 9093:9093
environment:
KAFKA_BROKER_ID: 2
KAFKA_ZOOKEEPER_CONNECT: zookeeper:2181
KAFKA_LISTENERS: INTERNAL://:29093,EXTERNAL://:9093
KAFKA_ADVERTISED_LISTENERS: INTERNAL://kafka2:29093,EXTERNAL://localhost:9093
KAFKA_LISTENER_SECURITY_PROTOCOL_MAP: INTERNAL:PLAINTEXT,EXTERNAL:PLAINTEXT
KAFKA_INTER_BROKER_LISTENER_NAME: INTERNAL
KAFKA_OFFSETS_TOPIC_REPLICATION_FACTOR: 1
kafdrop:
image: obsidiandynamics/kafdrop
restart: "no"
environment:
KAFKA_BROKERCONNECT: "kafka1:29092,kafka2:29093"
JVM_OPTS: "-Xms16M -Xmx512M -Xss180K -XX:-TieredCompilation -XX:+UseStringDeduplication -noverify"
ports:
- 9000:9000
depends_on:
- kafka1
- kafka2
sqlserver:
image: mcr.microsoft.com/mssql/server
ports:
- 1433:1433
environment:
- ACCEPT_EULA=Y
- MSSQL_PID=Standard
- SA_PASSWORD=sa.++112233
- MSSQL_AGENT_ENABLED=true
connect:
image: debezium/connect
ports:
- 8083:8083
environment:
CONFIG_STORAGE_TOPIC: my_connect_configs
OFFSET_STORAGE_TOPIC: my_connect_offsets
STATUS_STORAGE_TOPIC: my_connect_statuses
BOOTSTRAP_SERVERS: kafka1:29092,kafka2:29093
depends_on:
- kafka1
- kafka2
- zookeeper
- sqlserver
```
YML file above;
- Kafka1
- Kafka2
- Zookeeper
- Kafdrop (UI Tool)
- SQLServer
- Debezium
are configured for these services.
Then run the compose file with the following command.
`docker-compose up -d`
After these operations, we can perform database side operations
```sql
/* Creating database */
CREATE DATABASE DebeziumTestDB
/* Creating schema */
CREATE SCHEMA debezium
/* Creating table with schema */
CREATE TABLE debezium.products
(
id int primary key identity(1,1),
name nvarchar(200),
category nvarchar(max)
)
/* Activating database CDC */
EXEC sys.sp_cdc_enable_db
/* Activating table CDC */
USE DebeziumTestDB
EXEC sys.sp_cdc_enable_table
@source_schema = N'debezium',
@source_name = N'products',
@role_name = NULL,
@filegroup_name = N'',
@supports_net_changes = 0
```
After these operations, we need to establish a connection between debezium and the database. For this, we create a connector by making a POST request to a Rest API endpoint on the debezium side.
**Endpoint**: http://localhost:8083/connectors
**Body** :
```json
{
"name": "debezium-connector",
"config": {
"connector.class": "io.debezium.connector.sqlserver.SqlServerConnector",
"topic.creation.enable": true,
"topic.creation.default.replication.factor": 1,
"topic.creation.default.partitions": 10,
"topic.creation.default.cleanup.policy": "compact",
"topic.creation.default.compression.type": "lz4",
"auto.create.topics.enable": true,
"database.server.name": "dbserver1",
"database.hostname": "sqlserver",
"database.port": "1433",
"database.user": "sa",
"database.password": "sa.++112233",
"database.names": "DebeziumTestDB",
"database.whitelist": "debezium.products",
"database.history.kafka.topic": "dbhistory",
"database.encrypt": "false",
"database.history.kafka.bootstrap.servers": "kafka1:29092,kafka2:29093",
"table.whitelist": "products",
"schema.include.list": "debezium",
"schema.history.internal.kafka.topic": "schemahistory",
"schema.history.internal.kafka.bootstrap.servers": "kafka1:29092,kafka2:29093",
"table.include.list": "debezium.products",
"topic.prefix": "topicprefix"
}
}
```
After all these operations, let's create a Console application and access CDC data via Kafka.
```cs
using Confluent.Kafka;
try
{
var configuration = new ConsumerConfig()
{
GroupId = "topicprefix.DebeziumTestDB.debezium.products",
BootstrapServers = "localhost:9092"
};
using var consumer = new ConsumerBuilder(configuration).Build();
consumer.Subscribe("topicprefix.DebeziumTestDB.debezium.products");
while (true)
{
ConsumeResult value = consumer.Consume();
Console.WriteLine($"Value : {value.Value}");
}
}
catch (System.Exception ex)
{
Console.WriteLine(ex.Message);
}
```
If we run the application and the following query is run on the database side, we will get an answer like this.
```sql
INSERT INTO debezium.products
VALUES('product 6','test category 6')
```
```json
{
"schema": {
"type": "struct",
"fields": [
{
"type": "struct",
"fields": [
{
"type": "int32",
"optional": false,
"field": "id"
},
{
"type": "string",
"optional": true,
"field": "name"
},
{
"type": "string",
"optional": true,
"field": "category"
}
],
"optional": true,
"name": "topicprefix.DebeziumTestDB.debezium.products.Value",
"field": "before"
},
{
"type": "struct",
"fields": [
{
"type": "int32",
"optional": false,
"field": "id"
},
{
"type": "string",
"optional": true,
"field": "name"
},
{
"type": "string",
"optional": true,
"field": "category"
}
],
"optional": true,
"name": "topicprefix.DebeziumTestDB.debezium.products.Value",
"field": "after"
},
{
"type": "struct",
"fields": [
{
"type": "string",
"optional": false,
"field": "version"
},
{
"type": "string",
"optional": false,
"field": "connector"
},
{
"type": "string",
"optional": false,
"field": "name"
},
{
"type": "int64",
"optional": false,
"field": "ts_ms"
},
{
"type": "string",
"optional": true,
"name": "io.debezium.data.Enum",
"version": 1,
"parameters": {
"allowed": "true,last,false,incremental"
},
"default": "false",
"field": "snapshot"
},
{
"type": "string",
"optional": false,
"field": "db"
},
{
"type": "string",
"optional": true,
"field": "sequence"
},
{
"type": "string",
"optional": false,
"field": "schema"
},
{
"type": "string",
"optional": false,
"field": "table"
},
{
"type": "string",
"optional": true,
"field": "change_lsn"
},
{
"type": "string",
"optional": true,
"field": "commit_lsn"
},
{
"type": "int64",
"optional": true,
"field": "event_serial_no"
}
],
"optional": false,
"name": "io.debezium.connector.sqlserver.Source",
"field": "source"
},
{
"type": "string",
"optional": false,
"field": "op"
},
{
"type": "int64",
"optional": true,
"field": "ts_ms"
},
{
"type": "struct",
"fields": [
{
"type": "string",
"optional": false,
"field": "id"
},
{
"type": "int64",
"optional": false,
"field": "total_order"
},
{
"type": "int64",
"optional": false,
"field": "data_collection_order"
}
],
"optional": true,
"name": "event.block",
"version": 1,
"field": "transaction"
}
],
"optional": false,
"name": "topicprefix.DebeziumTestDB.debezium.products.Envelope",
"version": 1
},
"payload": {
"before": null,
"after": {
"id": 4,
"name": "product 6",
"category": "test category 6"
},
"source": {
"version": "2.2.0.Alpha3",
"connector": "sqlserver",
"name": "topicprefix",
"ts_ms": 1696104363803,
"snapshot": "false",
"db": "DebeziumTestDB",
"sequence": null,
"schema": "debezium",
"table": "products",
"change_lsn": "0000002a:000003a8:0002",
"commit_lsn": "0000002a:000003a8:0003",
"event_serial_no": 1
},
"op": "c",
"ts_ms": 1696104366879,
"transaction": null
}
}
```
