# Symbl-powered-Agora-RTE-app



[![Websocket](https://img.shields.io/badge/symbl-websocket-brightgreen)](https://docs.symbl.ai/docs/streamingapi/overview/introduction)



![](https://symbl.ai/wp-content/uploads/2021/05/symbl_agora_pn.jpg)



Symbl's APIs empower developers to enable:

- **Real-time** analysis of free-flowing discussions to automatically surface highly relevant summary discussion topics, contextual insights, suggestive action items, follow-ups, decisions, and questions.

- **Voice APIs** that makes it easy to add AI-powered conversational intelligence to either [telephony][telephony] or [WebSocket][websocket] interfaces.

- **Conversation APIs** that provides a REST interface for managing and processing your conversation data.

- **Summary UI** with a fully customizable and editable reference experience that indexes a searchable transcript and shows generated actionable insights, topics, timecodes, and speaker information.



**This app is provided for demonstration purposes only. Please feel free to report any issue in the `Issues` section.**






## Enable Symbl for Agora [RTE App][agorarte]






 * [Introduction](#introduction)

 * [Pre-requisites](#pre-requisites)

 * [Features](#features)

 * [Browser Support](#browsersupport)

 * [Setup and Deploy](#setupanddeploy)

 * [Dependencies](#dependencies)

 * [Conclusion](#conclusion)

 * [Community](#community)



## Introduction



This is a multi-party video-conferencing application that demonstrates [Symbl's Real-time APIs](https://docs.symbl.ai/docs/streamingapi/overview/introduction).



## Pre-requisites



* [Node.js v10+](https://nodejs.org/en/download/)

* [PostgreSQL Database](https://www.postgresql.org/)

* [Go](https://golang.org/)

* [Agora account](https://console.agora.io/)

* [Symbl account](https://platform.symbl.ai/#/signup?utm_source=get-info&utm_medium=marcelo&utm_campaign=rep)



## Features

* Live Closed Captioning

* Real-time Transcription

* Real-time Insights: Questions, Action Items and Follow-ups

* Real-time Topics with sentiments

* Video conferencing with real-time video and audio

* Enable/Disable camera

* Mute/unmute mic

* Screen sharing



## Browser Support

Support for this application is available only for Chrome and Firefox.



## Credentials



1. Get your Symbl credentials (`App Id` and `App Secret`) from the [Symbl Platform Console](https://platform.symbl.ai).



2. Get your Agora credentials (`App Id` and `App Certificate`) from the [Agora Platform Console](https://console.agora.io/). See [here](https://www.agora.io/en/blog/how-to-get-started-with-agora/) for more information on how to do that.



### Setup the Database

1. Download and install [PostgreSQL](https://www.postgresql.org/download/). You can follow these [steps to install PostgreSQL](https://www.postgresqltutorial.com/postgresql-getting-started/).

2. Create a database with the name of your choice. See [here](https://www.postgresql.org/docs/13/manage-ag-createdb.html) for more information.

3. Note the username, password, and database name that you have created.



### Setup the Backend



1. Clone the [repo](https://github.com/symblai/Symbl-powered-Agora-RTE-app).

2. Navigate to the `Symbl-Powered-Agora-Backend-master` directory and open the `config.json` file.

3. Add your Symbl `App Id` and `App Secret` values in the respective fields below:



```

"SYMBL_APPID": ""

"SYMBL_SECRET": ""

```

4. Add your Agora `App Id` and `App Certificate` values in the respective fields below:



```

"APP_ID": "",

"APP_CERTIFICATE": "",

```



5. Open the file models/db.go and replace the following line (19) within the CreateDB function:



```

db, err := gorm.Open("postgres", os.Getenv("PG_DB_DETAILS"))

```



with your PostgreSQL database user, password, host, and database name as described below:



```

db, err := gorm.Open("postgres","postgres://:@/?sslmode=disable")

```



This sample application uses GORM for connecting to the PostgreSQL database and you can learn more about it [here](https://gorm.io/docs/connecting_to_the_database.html).



### Run the Backend server



1. Navigate to the `Symbl-Powered-Agora-Backend-master` directory and run the following command:



```

go run server.go

```



Your backend server should be running on port `8080` and you should see a log message similar to the following:



```

{"level":"debug","time":"9999-99-99T99:99:99-07:00","message":"Backend server running on port: 8080"}

```



You can also navigate to http://localhost:8080/test to make sure the server is up and running without any issues. You should see a sample web page as shown below.



![](/sample-backend.png)



### Setup the Frontend



1. Open the file `config.json` under the folder `Symbl-Powered-Agora-Master` and provide your Agora project name, display name, and App Id in the respective fields below:



```

"projectName": ""

"displayName": ""

"AppID":""

```



2. Add the Backend URL in the respective field below:



```

"backEndURL": "http://localhost:8080"

```



### Run the Frontend



1. Navigate to the `Symbl-Powered-Agora-master` directory and run the following command:



```

npm install

```



This command will install all the necessary frontend dependencies.



2. Run the following command to start the frontend application:



```

npm run web

```



Your frontend server should be running on port 3000 (http://localhost:3000). You should see the web application ready to be used as shown below.



![](/sample-frontend.png)



### Testing the Application

With your backend and frontend servers up and running, navigate to [http://localhost:3000](http://localhost:3000), click on the `Create a meeting` button, enter a room name and click the `Create a meeting` button again.



When the meeting URL is created, click on the `Enter Meeting (as host)` button to enter the meeting.

Select your camera, microphone and type your display name before clicking on the `Join Room` button.



## Conclusion

This application allows you to join an Agora video conference meeting with Symbl Transcripts and Insights, Topics and Sentiments enabled and displayed it on the screen in real-time.



## Community



If you have any questions, feel free to reach out to us at [email protected] or through our [Community Slack][slack] or our [forum][developer_community].



This guide is actively developed, and we love to hear from you! Please feel free to [create an issue][issues] or [open a pull request][pulls] with your questions, comments, suggestions, and feedback. If you liked our integration guide, please star our repo!



This library is released under the [Apache License][license]
