# Gaze Correction Camera






MacOs Application Preview ([🔗 Download](https://drive.google.com/file/d/1E47OZ66YPab1QuTbxN97hL2u3GYwyUbz/view?usp=drive_link))



## Overview



This project implements a gaze correction system for video communication that uses computer vision and deep learning techniques to adjust eye gaze direction in real-time, providing a more natural eye contact experience during video calls. ([study more](./docs/orignal_doc.md))



## Demo
















## Prerequisites



Environment:



```text

ProductName:            macOS

ProductVersion:         15.2

BuildVersion:           24C101

```



The following dependencies are required to run this application:



- [Python 3.12+](https://www.python.org/downloads/)

- [Poetry](https://python-poetry.org/docs/) for dependency management

- [CMake](https://cmake.org/download/) (required for building dlib)

- [pkg-config](https://www.freedesktop.org/wiki/Software/pkg-config/) (required for certain dependencies)



## Installation



1. Install system dependencies:



   ```bash

   brew install pkg-config

   brew install cmake

   ```



2. Install Python dependencies using Poetry:



   ```bash

   poetry install

   ```



3. Download pretrained model files:



   Download the following files from [GitHub Releases](https://github.com/WangWilly/gaze-correction-cam/releases) and place them in the appropriate directories:

   - **Face landmark detector**: `shape_predictor_68_face_landmarks.dat`

     - Place in: `lm_feat/shape_predictor_68_face_landmarks.dat`

   - **Gaze correction model weights**: FLX model (Left and Right eye models)

     - Place in: `weights/warping_model/flx/12/L/` and `weights/warping_model/flx/12/R/`

     - Required files per directory: `checkpoint`, `L.data-00000-of-00001` / `R.data-00000-of-00001`, `L.index` / `R.index`, `L.meta` / `R.meta`



   - **(Optional) MediaPipe model**: `face_landmarker.task` (for MediaPipe backend)

     - Place in: `models/face_landmarker.task`

     - Download from [MediaPipe Solutions](https://developers.google.com/mediapipe/solutions/vision/face_landmarker)



## Usage



### Single Window Application (Recommended)



Run the simplified single-window gaze correction application:



```bash

# Using default dlib backend

poetry run python bin_single_window.py



# Using MediaPipe backend (requires face_landmarker.task)

poetry run python bin_single_window.py --backend mediapipe



# Specify camera device

poetry run python bin_single_window.py --camera 0

```



#### Controls



| Key | Action                        |

| --- | ----------------------------- |

| `g` | Toggle gaze correction on/off |

| `c` | Toggle calibration mode       |

| `q` | Quit application              |



#### Calibration Mode Controls



When calibration mode is enabled (press `c`):



| Key                          | Action                                 |

| ---------------------------- | -------------------------------------- |

| Arrow keys (`↑` `↓` `←` `→`) | Adjust camera offset X/Y (±0.5 cm)     |

| `+` / `-`                    | Adjust camera offset Z depth (±0.5 cm) |

| `[` / `]`                    | Adjust focal length (±10 pixels)       |

| `r`                          | Reset to default values                |



The calibration overlay displays:



- Current camera offset (X, Y, Z in cm)

- Estimated eye position (X, Y, Z in cm)

- Current focal length (in pixels)

- Top-view diagram showing camera, screen, and eye positions



## System Requirements



- macOS with camera access permissions

- Sufficient GPU resources for real-time processing

- Webcam or video capture device



## Architecture & Module Documentation



### System Overview



This is a **real-time gaze correction system** that redirects eye gaze in video streams to create natural eye contact during video calls. The system uses face detection, facial landmarks, and deep learning models to warp eye regions.



### File Structure & Module Organization



#### 1. Entry Points (bin\_\*.py)



##### bin*single_window.py ⭐ \_Main Application*



- **Purpose**: Single-window gaze correction app with real-time controls

- **Features**:

  - Auto-detects camera resolution

  - Toggle gaze correction on/off (`g` key)

  - Calibration mode for camera offset adjustment (`c` key)

  - Supports multiple backends (dlib/MediaPipe)

- **Flow**: `Camera Input → FacePredictor → GazeCorrector → Display Output`



##### bin_focal_length_calibration.py



- Standalone tool for camera focal length calibration



##### bin_test_mediapipe_detection.py



- Test utility for MediaPipe face detection



#### 2. Core Modules (displayers/)



The `displayers/` directory contains the main business logic components:



##### face_predictor.py - Face Detection & Landmark Extraction



**Purpose**: Abstract interface for face detection backends



**Key Classes**:



- `FacePredictor` (ABC): Interface for face detection

- `DlibFacePredictor`: Implementation using dlib (68 landmarks)

- `MediaPipeFacePredictor`: Implementation using Google MediaPipe

- Data classes: `FaceData`, `EyeData`, `EyeLandmarks`



**Process**: `Input Frame → Face Detection → Landmark Prediction → Eye Extraction → EyeData`



**Output**: `FaceData` containing:



- Left/right eye images (normalized 48×64)

- Anchor maps (feature point maps for spatial guidance)

- Eye center coordinates

- Original positions in frame



##### gaze_corrector.py - Gaze Correction Model



**Purpose**: Wraps TensorFlow models for eye gaze correction



**Key Classes**:



- `GazeModel`: TensorFlow model wrapper (loads L/R eye models)

- `GazeCorrector`: High-level interface for gaze correction

- `CameraConfig`: Camera geometry (focal length, IPD, camera offset)



**Process**:



```

EyeData + Camera Geometry → TF Model Inference → Warped Eye Image

                          ↓

                    Angle Calculation (3D geometry)

```



**Components**:



1. **Model Loading**: Loads separate L/R eye TensorFlow models from `weights/`

2. **Angle Calculation**: Computes gaze redirection angle based on:

   - Eye position in 3D space

   - Camera position relative to screen

   - Target gaze direction (toward camera)

3. **Eye Warping**: Applies learned transformation to redirect gaze



**Camera Geometry**:



- `focal_length`: Camera focal length (pixels)

- `ipd`: Inter-pupillary distance (cm)

- `camera_offset`: Camera position (X, Y, Z) relative to screen center



##### dis_single_window.py - Application Orchestrator



**Purpose**: Main application logic coordinating all components



**Key Class**: `SingleWindowGazeCorrector`



**Responsibilities**:



1. Camera capture and frame processing

2. FacePredictor → GazeCorrector pipeline

3. Real-time toggle controls

4. Calibration mode UI

5. Composite frame rendering



**Pipeline**:



```

Camera Frame

    ↓

Resize for Face Detection (320×240)

    ↓

FacePredictor.list_eye_data()

    ↓

For each eye:

    - If gaze_enabled: GazeCorrector.correct_eye()

    - Else: Use original eye image

    ↓

Composite corrected eyes onto original frame

    ↓

Draw status overlay

    ↓

Display in window

```



#### 3. TensorFlow Models (tf_models/)



##### flx.py - FLX Model Architecture



**Purpose**: Defines the neural network architecture for gaze correction



**Key Components**:



- `encoder()`: Encodes gaze angle into spatial feature map

- `trans_module()`: Transformation module with skip connections

- `apply_lcm()`: Light color modulation for realistic rendering

- `inference()`: Main forward pass combining all components



**Architecture**:



```

Eye Image + Anchor Map + Angle

    ↓

[Feature Extraction CNN]

    ↓

[Angle Encoder] → Spatial Feature Map

    ↓

[Transformation Module (Dense CNN)]

    ↓

[Flow Field Generation]

    ↓

[Spatial Transformer] → Warped Image

    ↓

[Light Color Modulation]

    ↓

Corrected Eye Image

```



##### transformation.py - Spatial Transformer



**Purpose**: Implements differentiable image warping



**Key Functions**:



- `meshgrid()`: Generates coordinate grid

- `interpolate()`: Bilinear interpolation for smooth warping

- `apply_transformation()`: Applies flow field to warp image



**Used for**: Applying learned pixel displacement fields to eye images



##### tf_utils.py



- Common TensorFlow utilities

- CNN/DNN blocks with batch normalization



#### 4. Utilities (utils/)



##### config.py - Configuration Management



**Purpose**: Centralized configuration using argparse



**Parameters**:



- Model dimensions (height=48, width=64, ef_dim=12)

- Camera parameters (focal length, IPD, camera offset)

- Network settings (IP, ports for multi-process mode)



##### logger.py - Logging Utility



**Purpose**: Formatted logging with timestamps and thread IDs



**Format**: `2026-01-27 10:30:45.123 Python[12345:67890] +[ClassName]: Message`



### Data Flow Pipeline



```

┌─────────────────────────────────────────────────────────────────┐

│                        MAIN APPLICATION                         │

│                     (bin_single_window.py)                      │

└──────────────────────┬──────────────────────────────────────────┘

                       │

                       ↓

         ┌─────────────────────────────┐

         │   Camera Capture (OpenCV)   │

         │   Original: 640×480         │

         └─────────────┬───────────────┘

                       │

                       ↓

         ┌─────────────────────────────┐

         │  Resize for Detection       │

         │  Downscaled: 320×240        │

         └─────────────┬───────────────┘

                       │

                       ↓

┌──────────────────────────────────────────────────────────────────┐

│                    FACE DETECTION LAYER                          │

│                  (displayers/face_predictor.py)                  │

├──────────────────────────────────────────────────────────────────┤

│  • Detect face(s) in frame                                       │

│  • Predict 68 facial landmarks (dlib) OR                         │

│  • Predict 478 landmarks (MediaPipe)                             │

│  • Extract eye regions (6 points per eye)                        │

│  • Resize eye images to 48×64                                    │

│  • Generate anchor maps (landmark feature maps)                  │

└─────────────┬────────────────────────────────────────────────────┘

              │

              ↓ Output: List[FaceData]

              │

┌─────────────────────────────────────────────────────────────────┐

│  FaceData {                                                     │

│    left_eye: EyeData {                                          │

│      image: 48×64×3 (normalized)                                │

│      anchor_map: 48×64×12 (feature points)                      │

│      center: (x, y)                                             │

│      top_left: (row, col)                                       │

│    }                                                            │

│    right_eye: EyeData {...}                                     │

│  }                                                              │

└─────────────┬───────────────────────────────────────────────────┘

              │

              ↓

┌──────────────────────────────────────────────────────────────────┐

│                   GAZE CORRECTION LAYER                          │

│                 (displayers/gaze_corrector.py)                   │

├──────────────────────────────────────────────────────────────────┤

│  For each eye:                                                   │

│    1. Calculate 3D eye position from landmarks                   │

│    2. Compute gaze redirection angle (toward camera)             │

│    3. Feed to TensorFlow model:                                  │

│       • Eye image (48×64×3)                                      │

│       • Anchor map (48×64×12)                                    │

│       • Gaze angle (θx, θy)                                      │

│    4. Model outputs warped eye image                             │

└─────────────┬────────────────────────────────────────────────────┘

              │

              ↓

┌──────────────────────────────────────────────────────────────────┐

│                      TensorFlow MODEL                            │

│                     (tf_models/flx.py)                           │

├──────────────────────────────────────────────────────────────────┤

│  [Encoder] → Angle to spatial feature map                        │

│  [CNN Feature Extraction] → Image features                       │

│  [Transformation Module] → Flow field prediction                 │

│  [Spatial Transformer] → Apply warping                           │

│  [Light Color Module] → Adjust lighting                          │

└─────────────┬────────────────────────────────────────────────────┘

              │

              ↓ Corrected Eye Image (48×64×3)

              │

┌──────────────────────────────────────────────────────────────────┐

│                    COMPOSITE & DISPLAY                           │

│                (dis_single_window.py)                            │

├──────────────────────────────────────────────────────────────────┤

│  1. Resize corrected eyes back to original size                  │

│  2. Paste onto original 640×480 frame at eye positions           │

│  3. Draw status overlay (GAZE ON/OFF)                            │

│  4. Draw calibration overlay (if enabled)                        │

│  5. Display in OpenCV window                                     │

└──────────────────────────────────────────────────────────────────┘

```



### Key Design Patterns



#### 1. Dependency Injection



- `FacePredictor` is injectable → easy to swap backends (dlib ↔ MediaPipe)

- `GazeCorrector` is injectable → testable and modular



#### 2. Abstract Interface



- `FacePredictor` is abstract base class

- Implementations: `DlibFacePredictor`, `MediaPipeFacePredictor`



#### 3. Configuration Objects



- Dataclasses for configuration (immutable, type-safe)

- `DisplayConfig`, `CameraConfig`, `GazeModelConfig`, etc.



#### 4. Separation of Concerns



- Face detection ≠ Gaze correction

- Display logic ≠ Model inference

- Configuration ≠ Business logic



### Module Responsibilities



| Module                | Input                      | Output           | Responsibility                    |

| --------------------- | -------------------------- | ---------------- | --------------------------------- |

| **face_predictor**    | Frame (BGR)                | `List[FaceData]` | Detect faces, extract eye regions |

| **gaze_corrector**    | `FaceData` + Camera Config | Corrected frame  | Apply gaze correction model       |

| **flx.py**            | Eye image + Anchor + Angle | Warped eye       | Neural network inference          |

| **transformation.py** | Flow field + Image         | Warped image     | Spatial transformation            |

| **dis_single_window** | Camera stream              | Display window   | Orchestrate pipeline, UI          |



### How It Works (High-Level)



1. **Capture** video frame from webcam

2. **Detect** face and extract 68 facial landmarks

3. **Extract** left/right eye regions (48×64 each)

4. **Calculate** 3D eye position and required gaze angle

5. **Inference** through trained CNN to generate warping flow field

6. **Warp** eye image using spatial transformer

7. **Composite** corrected eyes back onto original frame

8. **Display** result in real-time



The key innovation is the **learned warping transformation** that realistically redirects gaze while preserving eye appearance, lighting, and texture.



## References



The implementation is based on research in gaze correction techniques using warping-based convolutional neural networks.
