# Task Service - Case Study

## Table of Contents
- [Quick Start](#quick-start)
- [Manual Setup](#manual-setup)
- [Project Structure](#project-structure)
- [Architecture](#architecture)
- [Database Schema](#database-schema)
- [API Documentation](#api-documentation)
- [CLI Usage](#cli-usage)
- [Additional Information](#additional-information)
- [Plugin Model](#plugin-model)
- [Testing in Kubernetes with Kind](#testing-in-kubernetes-with-kind)
- [Improvement](https://github.com/yindia/iteration/tree/postgres?tab=readme-ov-file#future-improvements)

## Quick Start
To quickly get started with the Task Service, use the following command:

```bash
make bootstrap

docker-compose -f docker-compose.demo.yaml up
```

This will start all the necessary services, including the server, database, and worker.

## Manual Setup

For a more detailed setup process, follow these steps:

### 1. Development Environment Setup
Install Pixi and activate the shell:
```bash
make bootstrap

# Run Database
docker-compose up -d
```

### 2. Server (Control Plane)
Start the server:
```bash
make run-server
```
Access at https://127.0.0.1:8080

### 3. CLI Tool
Build and test:
```bash
make build-cli
./bin/task-cli --help
```

### 4. Dashboard Setup
Install dependencies and build:
```bash
npm install
npm run dev
```
Access at https://127.0.0.1:3000

Screenshot 2024-09-29 at 4 22 37 PM

### 5. Worker (Data Plane)
Start worker instances:
```bash
./bin/task-cli serve --log-level debug
```

## Project Structure
```
task/
├── cmd/
│ ├── cli/ # CLI for task management
│ └── server/ # Server entry point
├── pkg/
│ ├── config/ # Configuration management
│ ├── gen/ # GRPC generated code
│ ├── plugins/ # Plugin model
│ ├── worker/ # Worker code
│ └── x/ # Utility functions
├── idl/
│ └── proto/ # Protocol buffer definitions
├── clients/
│ └── dashboard/ # NextJS Dashboard
├── charts/
│ └── task/ # Helm charts for deployment
├── server/
│ ├── repository/ # Database ORM
│ └── root/ # Server Root
│ └── route/ # All Server Routes
└── docs/ # Documentation files
```

## Architecture

The Task Service follows a distributed architecture with separate components for the control plane and data plane. Here's a high-level overview of the system:

```mermaid
graph TD
%% Clients
A[Dashboard Client] -->|Sends Request| B(Server)
C[CLI Client] -->|Sends Request| B(Server)

%% Control Plane
subgraph Control Plane
B(Server) -->|Reads/Writes| D[(PostgreSQL Database)]
end

This architecture allows for:
- Separation of concerns between the control plane (server) and data plane (workers)
- Scalability of worker nodes to handle increased workloads
- Asynchronous task execution through message queuing
- Real-time status updates from workers to the server

### Database Operations

The server interacts with the database for persistent storage of tasks and their history. Here's a summary of the database operations:

1. **Read Operations**
- Get Task by ID
- Purpose: Retrieve details of a specific task
- Frequency: On-demand, triggered by API requests
- List All Tasks
- Purpose: Retrieve a list of all tasks
- Frequency: On-demand, typically for dashboard or reporting
- List Task History
- Purpose: Retrieve the status change history of a specific task
- Frequency: On-demand, for detailed task analysis

2. **Write Operations**
- Create New Task
- Purpose: Store a newly created task
- Frequency: Each time a new task is submitted
- Update Task Status
- Purpose: Modify the status of an existing task
- Frequency: As task states change (e.g., from queued to running to completed)
- Create Task History Entry
- Purpose: Log task status changes and creation events
- Frequency: On task creation and each status change

### Database Schema

The Task Service uses a PostgreSQL database to store task and task history information. Below is an Entity-Relationship Diagram (ERD) representing the database schema:

```mermaid
erDiagram
%% Task Model
TASK {
int id PK
string name
int type
int status
jsonb payload
int retries
int priority
timestamp created_at
}

%% TaskHistory Model
TASK_HISTORY {
int id PK
int task_id FK
int status
string details
timestamp created_at
}

%% Relationships
TASK ||--o{ TASK_HISTORY : has

%% Indexes (described as comments)
%% Indexes for TASK
%% - idx_type_status (type, status)
%% - idx_created_at (created_at)
%% - idx_status_created_at (status, created_at)

%% Indexes for TASK_HISTORY
%% - idx_task_id_created_at (task_id, created_at)
```

Note: Ideally, we should create separate tables for tasks 📝 and task executions ⚙️. When a task is created, it should be added to the task table. Upon triggering an execution, a corresponding entry should be created in the execution table, and the execution data should be published to the PostgreSQL queue for processing 📬. This way, the task status remains unchanged, and only the execution status is updated in the execution table ✅.

### Table Descriptions

1. **TASK**
- Stores information about individual tasks
- `id`: Unique identifier for the task (Primary Key)
- `name`: Name of the task
- `type`: Type of the task (e.g., send_email, run_query)
- `status`: Current status of the task (e.g., pending, running, completed)
- `payload`: JSON object containing task-specific parameters
- `retries`: Number of retry attempts for the task
- `priority`: Priority level of the task
- `created_at`: Timestamp of task creation

2. **TASK_HISTORY**
- Tracks the history of status changes for tasks
- `id`: Unique identifier for the history entry (Primary Key)
- `task_id`: Foreign Key referencing the TASK table
- `status`: Status of the task at the time of the history entry
- `details`: Additional details about the status change
- `created_at`: Timestamp of the history entry creation

### Relationships

- One TASK can have many TASK_HISTORY entries (one-to-many relationship)

### Indexes

To optimize query performance, the following indexes are implemented:

1. **TASK table**
- `idx_type_status`: Composite index on `type` and `status` columns
- `idx_created_at`: Index on `created_at` column
- `idx_status_created_at`: Composite index on `status` and `created_at` columns

2. **TASK_HISTORY table**
- `idx_task_id_created_at`: Composite index on `task_id` and `created_at` columns

These indexes improve the efficiency of common queries such as filtering tasks by type and status, sorting by creation time, and retrieving task history.

### Worker/Data Plane Process

The worker process follows a specific flow for task execution and error handling. Here's a detailed view of the worker's operation:

```mermaid
graph TD
A[Receive Message] --> B{Update Status: RUNNING}
B -->|Success| C[Run Task]
B -->|Failure| D[Log Error]
D --> K[Move to Next Message]

C --> E{Task Execution}
E -->|Success| F[Update Status: SUCCEEDED]
E -->|Failure| G[Retry Logic]

G --> H{Retry Attempt <= 3?}
H -->|Yes| I[Backoff]
I --> J[Update Status: RETRYING]
J --> C
H -->|No| K[Update Status: FAILED]

F --> L[Move to Next Message]
K --> L
```

## API Documentation
- [Proto Docs](https://buf.build/evalsocket/cloud)
- [Studio](https://buf.build/studio/evalsocket/cloud/cloud.v1.TaskManagementService/CreateTask)

## CLI Usage

### Task Management

The Task Service CLI provides several commands to manage tasks. Here's a detailed overview of each command and its available flags:

#### Create a Task

Create a new task with the specified name, type, and parameters.

```bash
task-cli task create [task name] --type [task type] --parameter [key=value]
```

Flags:
- `--type`, `-t`: Type of the task (e.g., send_email, run_query)
- `--parameter`, `-p`: Additional parameters for the task as key=value pairs (can be used multiple times)

Example:
```bash
task-cli task create "Send Newsletter" --type send_email --parameter [email protected] --parameter subject="Weekly Update"
```

#### Get Task Details

Retrieve and display the details of a specific task by its ID.

```bash
task-cli task get --id [task ID] [flags]
```

Flags:
- `--id`, `-i`: ID of the task (required)
- `--output`, `-o`: Output format (table, json, yaml) (default: "table")

Example:
```bash
task-cli task get --id 123 --output json
```

#### Get Task History

Retrieve and display the history of a specific task by its ID.

```bash
task-cli history --id [task ID] [flags]
```

Flags:
- `--id`, `-i`: ID of the task (required)
- `--output`, `-o`: Output format (table, json, yaml) (default: "table")

Example:
```bash
task-cli history --id 123 --output yaml
```

#### List All Tasks

Retrieve and display a list of all tasks.

```bash
task-cli task list [flags]
```

Flags:
- `--output`, `-o`: Output format (table, json, yaml) (default: "table")
- `--pageNumber`, `-n`: Page number for pagination (default: 1)
- `--pageCount`, `-c`: Number of items per page (default: 30)

Examples:
```bash
task-cli task list
task-cli task list --output json
task-cli task list --pageNumber 2 --pageCount 20
```

#### Task Status

Retrieve the status counts of all tasks in the system.

```bash
task-cli task status
```

Aliases: `s`, `stat`

Example:
```bash
task-cli task status
task-cli task s
```

This command will display the count of tasks for each status (e.g., PENDING, RUNNING, SUCCEEDED, FAILED).

#### End-to-End Testing

Run end-to-end tests against the system to verify its functionality.

```bash
task-cli end2end [flags]
```

Flags:
- `--num-tasks`, `-n`: Number of tasks to create for the test (default: 100, max: 100)

Example:
```bash
task-cli end2end
task-cli end2end -n 50
```

This command will:
1. Create the specified number of tasks (default 100)
2. Monitor the tasks' completion status for up to 3 minutes
3. Display progress every 5 seconds
4. Report the final result (success or partial completion)

The test creates a mix of "run_query" and "send_email" task types to simulate a realistic workload.

### Global Flags

The following flag is available for all task commands:

- `--log-level`: Set the logging level (default: "error")
- `--address`: Control Plane Address (default: "http://127.0.0.1:8080")

Example:
```bash
task-cli task list --log-level debug
```

### Output Formats

All commands that display task information support three output formats:

- `table`: Displays the information in a formatted table (default)
- `json`: Outputs the data in JSON format
- `yaml`: Outputs the data in YAML format

Use the `--output` or `-o` flag to specify the desired format.

## Additional Information
- Control plane (server) manages task creation, scheduling, and status updates
- Data plane (workers) executes tasks (Currently part of same binary)
- RiverQueue used for communication between control and data planes using postgres as queue backend
- Explore the UI or CLI to create and manage tasks

## Plugin Model

The Task Service uses a plugin-based architecture to allow for extensibility and customization of task execution. This model enables users to create their own task types and implement custom logic for task execution.

### How It Works

1. **Plugin Interface**: All plugins must implement the `Plugin` interface defined in `@pkg/plugins/plugins.go`. This interface requires a `Run` method:

```go
type Plugin interface {
Run(parameters map[string]string) error
}
```

2. **Plugin Registration**: Plugins are registered in the `NewPlugin` function in `@pkg/plugins/plugins.go`. This function acts as a factory, creating the appropriate plugin based on the task type:

```go
func NewPlugin(pluginType string) (Plugin, error) {
switch pluginType {
case email.PLUGIN_NAME:
return &email.Email{}, nil
case query.PLUGIN_NAME:
return &query.Query{}, nil
// Add more plugin types here
default:
return nil, fmt.Errorf("unknown plugin type: %s", pluginType)
}
}
```

3. **Custom Plugin Implementation**: Users can create their own plugins by implementing the `Plugin` interface. For example, the `Email` plugin in `@pkg/email/email.go`:

```go
var PLUGIN_NAME = "send_email"
type Email struct {}

func (e *Email) Run(parameters map[string]string) error {
// Implementation of email sending logic
return nil
}
```

4. **Task Execution**: When a task is executed, the system uses the `NewPlugin` function to create the appropriate plugin based on the task type. It then calls the `Run` method of the plugin, passing any necessary parameters.

### Creating a New Plugin

To create a new plugin:

1. Create a new package in the `@pkg/plugins` directory for your plugin.
2. Implement the `Plugin` interface in your new package.
3. Add your plugin to the `NewPlugin` function in `@pkg/plugins/plugins.go`.

This modular approach allows for easy extension of the Task Service with new task types and functionalities.

## Testing in Kubernetes with Kind

This section guides you through setting up and testing the Task Service in a local Kubernetes cluster using Kind (Kubernetes in Docker) and Helm charts.

### Prerequisites

- [Docker](https://docs.docker.com/get-docker/)
- [Kind](https://kind.sigs.k8s.io/docs/user/quick-start/#installation)
- [kubectl](https://kubernetes.io/docs/tasks/tools/)
- [Helm](https://helm.sh/docs/intro/install/)

### Setup

1. Create a Kind cluster:

```bash
kind create cluster --name task-service
```

2. Set kubectl context to the new cluster:

```bash
kubectl cluster-info --context kind-task-service
```

3. Add the necessary Helm repositories:

```bash
make helm
```

### Deploy Task Service

Install the Task Service Helm chart:

```bash
helm install task-service ./charts/task -n task
```

### Verify Deployment

Check that all pods are running:

```bash
kubectl get pods
```

## Port Forward
```
kubectl port-forward service/task 80 -n task
```

### Access the Service

1. Port-forward the Task Service:

```bash
kubectl port-forward -n task svc/task 8080:80
```

2. Access the service at `http://127.0.0.1:8080`

3. Use CLI to verify the connection:
```bash
./bin/task-cli task l --address http://127.0.0.1:8080
```

### Clean Up

To delete the Kind cluster and all resources:

```bash
kind delete cluster --name task-service
```

This setup allows you to test the entire Task Service stack, including the server, workers, and dependencies, in a local Kubernetes environment. It's an excellent way to validate the Helm charts and ensure everything works together as expected in a Kubernetes setting.
